Page 18 December 2007
ZB2044
Section 2 - Operation
2.2 Major Components
ZB2044 Telehandler
ZB2044 Telehandler
Attachment Tilt
Cylinders
Boom Assembly
Boom Angle Indicator
Operator’s
Cab
Boom Lift Cylinder
Engine Air Intake
Front Axle
and Tire
Rear Axle
and Tire
Rear Axle
Lock Cylinder
Outriggers
Fork Carriage
Attachment
Frame Level Cylinders
