2.3 Major Assemblies
The telehandler consists of four major assemblies: the
frame, boom assembly, attachment and cab.
2.3-1 Frame
The frame is a one-piece weldment that supports the
boom assembly. The parking brake is a pinion-mounted
disc brake on the front axle. ZB2044 model is equipped
with a dual service brake system.
2.3-2 Cab
The cab is the safety structure enclosing the operator.
It also furnishes the controls of the telehandler.
2.3-3 Boom Assembly
The boom is mounted on the frame and supported
by lift cylinders on each side of the frame. The boom
assembly consists of main boom section and primary
boom section, as well as a third boom section.
Boom assembly also includes a subcarriage which
is mounted to the yoke and is supported by two tilt
cylinders.
2.3-4 Attachment
The attachment is a material-handling device attached
to the boom. The standard attachment is a fork carriage
attachment. The standard carriage is available in 60”,
72” and 84” widths. Optional attachments include
combination fork positioner/sideshift attachment, fork
positioner, pipe and pole clamp and grapple, coil
boom, bridge stripper, light material bucket, jib boom,
& winch attachment. Refer to Section 2.15 for optional
attachments.
2.4 Serial Number Nameplate
The serial number nameplate is located inside the
operator’s cab and lists the following:
• Model number
• Serial number
• Maximum capacity
• Maximum lift height
• Maximum machine weight without attachment
• Original supplied attachments
• Year of manufacture
• Voltage
