PJC 221 & 222
PDC-301 Fault Codes
MC_0119
Fault Code Fault Name Fault Description Action
10600.0.208 Retract Controller - INTERLOCK Retract Interlock
-Check if retract is deployed.
-No communication with Retract Controller, check if Retract Control-
ler has power.
-Check PDC-301 and Retract Controller setup.
36100.1.24 VFD Instance 1 Fault VFD faulted -See VFD for more information
36100.1.100 VFD Instance 1 No Communication PDC-301 has no MODBUS communication with VFD.
-Check communication cable with VFD
-Check if VFD has power
36101.1.200 VFD PMS Instance 1 Timeout VFD is not ready within 60 after power request. -Check if VFD has power
36101.1.204 VFD PMS Instance 1 SIGNAL LOST
Lost Power Management signal from VFD, VFD not available
anymore.
-Check VFD for more information.
36103.1.0 VFD IN LOCAL Instance 1 - VFD in Local or Hand Mode -Change mode in VFD panel.
eVision and EHP Fault Codes
MC_0529
Fault Code Fault Name Fault Description Action
100.0.0 System Error - - Internal error -Consult Side-Power dealer
107.0.24 Bootloader fault code - Fault Bootloader failed upgrading.
-Check S-link cables and T-connectors.
-If problem persist, consult Sleipner dealer.
155.0.24 Internal Voltage - Fault Internal error -If problem persist, consult Sleipner dealer.
10000.106.55 Motor Temp eVision Controller uC Overtemp Stator over temperature -Wait for motor to cool down
10002.0.13 Stator Temperature - Open Circuit Stator temperature sensor not connected -If problem persist, consult Sleipner dealer.
10002.0.16 Stator Temperature - Short Circuit Stator temperature sensor short circuit -If problem persist, consult Sleipner dealer.
10003.0.13 Transistor Temperature - Open Circuit Transistor temperature sensor not connected -If problem persist, consult Sleipner dealer.
10003.0.16 Transistor Temperature - Short Circuit Transistor temperature sensor short circuit -If problem persist, consult Sleipner dealer.
10101.106.55 Device CPU Temp eVision Controller uC Overtemp Main MCU temperature above max limit -Wait for motor to cool down
10101.107.55 Device CPU Temp eVision Motor uC Overtemp Motor MCU temperature above max limit -Wait for motor to cool down.
10102.106.55 Device Board Temperature eVision Controller uC Overtemp Transistor over temperature -Wait for motor to cool down
10104.106.24 Motor Speed eVision Controller uC Fault Motor speed outside valid range. -Check propeller blades and flexible coupling.
10104.107.212 Motor Speed eVision Motor uC Overspeed Motor speed outside valid range
-Check propeller blades and flexible coupling.
-If not resolved consult Sleipner represen-
tative.
10200.106.53 System Voltage eVision Controller uC Overvoltage Main MCU temperature above max limit
-Measure voltage at battery terminals and
thruster terminals.
10200.106.54 System Voltage eVision Controller uC Undervoltage Motor supply voltage below min limit
-Measure voltage at battery terminals and
thruster terminals.
10200.107.53 System Voltage eVision Motor uC Overvoltage Motor supply voltage above max limit
-Measure voltage at battery terminals and
thruster terminals.
10200.107.54 System Voltage eVision Motor uC Undervoltage Motor supply voltage below min limit
-Measure voltage at battery terminals and
thruster terminals.
10301.0.100 Motor Position - No Communication Communication with speed sensor failed -If problem persist, consult Sleipner dealer.
10301.107.212 Motor Position eVision Motor uC Overspeed Motor fails to stop correctly -If problem persist, consult Sleipner dealer.
10302.107.24 uC Communication eVision Motor uC Fault Communication between internal MCUs failed -If problem persist, consult Sleipner dealer.
10302.107.100 uC Communication eVision Motor uC No Communication Communication between internal MCUs timeout -If problem persist, consult Sleipner dealer.
10303.107.20 Motor Torque eVision Motor uC Over Limit Motor torque above max limit
-Check if propeller is obstructed.
-If not resolved consult Sleipner dealer.
10600.0.24 Retract Controller - Fault Fault detected on retract -Check retract faults
10600.0.208 Retract Controller - INTERLOCK
Function or Location confi guration does not match
retract controller confi guration
-Check confi guration of installed devices.
30100.0.13 Thruster Motor Current - Open Circuit Motor phase not connected. -If problem persist, consult Sleipner dealer.
30100.107.57 Thruster Motor Current eVision Motor uC Overcurrent Measured motor phase current above max limit
-Check if propeller is blocked.
-If not resolved consult Sleipner dealer.
60000.0.13 Main Fan - Open Circuit Cooling fan temperature measurement open circuit -If problem persist, consult Sleipner dealer.
60000.0.16 Main Fan - Short Circuit Cooling fan temperature measurement short circuit -If problem persist, consult Sleipner dealer.
60000.0.50 Main Fan - Current Low Cooling fan current consumption below min limit -If problem persist, consult Sleipner dealer.
60000.0.51 Main Fan - Current High Cooling fan current consumption above max limit -If problem persist, consult Sleipner dealer.
60000.0.53 Main Fan - Overvoltage Cooling fan supply voltage above max limit -If problem persist, consult Sleipner dealer.
60000.0.54 Main Fan - Undervoltage Cooling fan supply voltage below min limit -If problem persist, consult Sleipner dealer.
60000.0.55 Main Fan - Overtemp
Cooling fan power supply temperature above max
limit
-Wait for motor to cool down
60000.0.211 Main Fan - Underspeed Cooling fan speed below limit -If problem persist, consult Sleipner dealer.
60000.0.212 Main Fan - Overspeed Cooling fan speed above limit -If problem persist, consult Sleipner dealer.
PHC-3 Fault Codes
MC_0117
Fault Code Fault Name Fault Description Action
10524.0.100 PHC ECI Cooling Pump - No Communication No communication with ECI cooling pump
-Check if ECI pump is connected
-Check wires to ECI pump for open circuits
-Check power supply cooling pump
-Wrong cooling pump confi gured, parameter 0301
10524.0.205 PHC ECI Cooling Pump - HW FAULT ECI cooling pump hardware fault -Replace ECI cooling pump
10526.0.0 PHC ECI Cooling Pump Blocked - - ECI cooling pump is blocked
-Reset fault and if fault reappears, cooling pump need service or
replacement.
-Check pump inlet for obstacles
10527.1.0 PHC VFD Not Ready Instance 1 - VFD not ready -VFD external run enable/power available signal is lost.
10528.1.10
PHC VFD ABB Parameter Instance 1 Level
Low
ABB ACS550 parameter values 2001 or 2002 cannot be a
negative value.
-Check ABB ACS550 parameter 2001 and 2002.
10529.0.19 PHC ECI Cooling Pump Speed - Under Limit
ECI pump motor speed under limit. Motor speed is below 100
rpm, or not getting minimum 750 rpm within 3 seconds.
-Check hose for dirt
-Check pump inlet for obstacles
10530.0.201 PHC PTO ENGINE INSTANCE - INIT FAIL Parameter 1011-PTO ENGINE INSTANCE is not defi ned -Set parameter 1011-PTO ENGINE INSTANCE
10531.0.100 CC MODULE - No Communication No communication with CC Module
-Check if CC Module is connected
-Check wires to CC Module for open circuits
-Check power supply CC Module
10532.0.24 CC MODULE AC PUMP - Fault
The CC Module AC pump circuit is open and pump is not
running
-Check if AC generator is running
-Check if the AC pump contactor is tripped
-Check wires to the pump for open circuit
10533.0.24 CC MODULE DC PUMP - Fault
The CC Module DC pump circuit is open and pump is not
running
-Check if DC pump contactor has 24VDC
-Check if the DC pump contactor is tripped
-Check wires to the DC pump for open circuit
10600.202.208 Retract Controller Bow INTERLOCK Retract Interlock Bow
-Check if retract is deployed.
-No communication with Retract Controller, check if Retract Con-
troller has power and S-link communication.
-Check PHC-3 and Retract Controller for correct setup.
10600.203.208 Retract Controller Bow Starboard INTERLOCK Retract Interlock Bow Starboard
-Check if retract is deployed.
-No communication with Retract Controller, check if Retract Con-
troller has power and S-link communication.
-Check PHC-3 and Retract Controller for correct setup.
10600.204.208 Retract Controller Bow Port INTERLOCK Retract Interlock Bow Port
-Check if retract is deployed.
-No communication with Retract Controller, check if Retract Con-
troller has power and S-link communication.
-Check PHC-3 and Retract Controller for correct setup.
10600.205.208 Retract Controller Stern INTERLOCK Retract Interlock Stern
-Check if retract is deployed.
-No communication with Retract Controller, check if Retract Con-
troller has power and S-link communication.
-Check PHC-3 and Retract Controller for correct setup.
10600.206.208
Retract Controller Stern Starboard INTER-
LOCK
Retract Interlock Stern Starboard
-Check if retract is deployed.
-No communication with Retract Controller, check if Retract Con-
troller has power and S-link communication.
-Check PHC-3 and Retract Controller for correct setup.
10600.207.208 Retract Controller Stern Port INTERLOCK Retract Interlock Stern Port
-Check if retract is deployed.
-No communication with Retract Controller, check if Retract Con-
troller has power and S-link communication.
-Check PHC-3 and Retract Controller for correct setup.
36000.1.24 ABB ACS550 Instance 1 Fault ABB ACS550 fault Se ABB ACS550 drive for more details
36002.1.24 VACON Instance 1 Fault VACON VFD Fault Se VACON drive for more details
36003.1.24 ABB ACS580 Instance 1 Fault ABB ACS580 fault Se ABB ACS580 drive for more details
36004.1.24 EHP Instance 1 Fault EHP Fault -See fault from EHP for more details
36100.1.100 VFD Instance 1 No Communication Lost communication with VFD
-VFD not powered up
-VFD communication cable not connected or incorrectly wired
-On the VFD make sure the RS485 BUS TERMINATION is in ON
position
36103.1.0 VFD IN LOCAL Instance 1 - VFD in local mode -Switch VFD to remote mode
