PJC 221 & 222
SRC-3 Fault Codes
MC_0636
Fault Code Fault Name Fault Description Action
100.0.0 System Error - - System Error Contact Sleipner Dealer
153.0.151 Supply Voltage - Self-Test Fault Failed to determine voltage level of the system / Out of range.
Verify that the correct battery was chosen for this system and that
it is properly charged.
10600.0.101 Retract Controller - Bus Off Actuator CAN experienced Bus Off/Bus error. Verify CAN cables to the actuators are correctly connected.
10600.0.210 Retract Controller - Service Mode In Service Mode. Exit service mode by using button controls.
10602.0.22 Retract Motion OUT Fault - Out of position
Lift or Lock Actuators went past their expected end-position
when hatch deploying.
Verify the mechanical shape of the hatch is according to specifi ca-
tion. Check fault specifi c for more info.
10602.0.51 Retract Motion OUT Fault - Current High Blocked while deploying hatch. Find and remove cause of mechanical blockage.
10603.0.22 Retract Motion IN Fault - Out of position
Lift or Lock Actuators went past their expected end-position
when hatch retracting.
Verify the mechanical shape of the hatch is according to specifi ca-
tion. Check fault specifi c for more info.
10603.0.51 Retract Motion IN Fault - Current High Blocked while retracting hatch. Find and remove cause of mechanical blockage.
10605.1.24 Lift Actuator Instance 1 Fault Lift Actuator 1 Reported a Fatal Error, could be broken. Contact Sleipner Dealer.
10605.1.53 Lift Actuator Instance 1 Overvoltage Lift Actuator 1 Measured Overvoltage Verify that the correct battery was chosen for this system.
10605.1.54 Lift Actuator Instance 1 Undervoltage Lift Actuator 1 Measured Undervoltage Verify that battery is charged.
10605.1.55 Lift Actuator Instance 1 Overtemp Lift Actuator 1 Temperature Exceeding >85C Find and eliminate cause of high temperature.
10605.1.100 Lift Actuator Instance 1 No Communication Lift Actuator 1 Not Communicating
Verify that CAN and supply cables are correctly connected, and that
no fuses have gone out.
10605.1.209 Lift Actuator Instance 1 MOTION FAULT
Lift Actuator 1 experienced linear motion while it was
supposed to be in a fi xed position. Load might have caused
backdrive.
Look for mechanical obstruction/causes for the backdrive and
remove them.
10605.2.24 Lift Actuator Instance 2 Fault Lift Actuator 2 Reported a Fatal Error, could be broken. Contact Sleipner Dealer.
10605.2.53 Lift Actuator Instance 2 Overvoltage Lift Actuator 2 Measured Overvoltage Verify that the correct battery was chosen for this system.
10605.2.54 Lift Actuator Instance 2 Undervoltage Lift Actuator 2 Measured Undervoltage Verify that battery is charged.
10605.2.55 Lift Actuator Instance 2 Overtemp Lift Actuator 2 Temperature Exceeding >85C Find and eliminate cause of high temperature.
10605.2.100 Lift Actuator Instance 2 No Communication Lift Actuator 2 Not Communicating
Verify that CAN and supply cables are correctly connected, and that
no fuses have gone out.
10605.2.209 Lift Actuator Instance 2 MOTION FAULT
Lift Actuator 2 experienced linear motion while it was
supposed to be in a fi xed position. Load might have caused
backdrive.
Look for mechanical obstruction/causes for the backdrive and
remove them.
10606.1.24 Lock Actuator Instance 1 Fault Lock Actuator 1 Reported a Fatal Error, could be broken. Contact Sleipner Dealer.
10606.1.53 Lock Actuator Instance 1 Overvoltage Lock Actuator 1 Measured Overvoltage Verify that the correct battery was chosen for this system.
10606.1.54 Lock Actuator Instance 1 Undervoltage Lock Actuator 1 Measured Undervoltage Verify that battery is charged.
10606.1.55 Lock Actuator Instance 1 Overtemp Lock Actuator 1 Temperature Exceeding >85C Find and eliminate cause of high temperature.
10606.1.100 Lock Actuator Instance 1 No Communication Lock Actuator 1 Not Communicating
Verify that CAN and supply cables are correctly connected, and that
no fuses have gone out.
10606.1.209 Lock Actuator Instance 1 MOTION FAULT
Lock Actuator 1 experienced linear motion while it was
supposed to be in a fi xed position. Load might have caused
backdrive.
Look for mechanical obstruction/causes for the backdrive and
remove them.
10607.0.209 Actuator Alignment Fault - MOTION FAULT
There was a position discrepancy between the lift actuators,
but alignment failed.
Look for mechanical obstruction/causes for alignment failure.
40008.0.206 SCU Sensor board fault 6 - WRITE FAIL EEPROM failed to write. Contact Sleipner Dealer.
When installing an S-Link™ system connect ONLY original Sleipner S-Link™ products or other authorized control equipment directly to the S-Link™ bus.
Connecting non-authorized third-party equipment, it must always be connected through a Sleipner supplied interface product.
Any attempt to directly control or connect into the S-Link™ control system without a designated and approved interface will render all warranties and
responsibilities of all of the connected Sleipner products. If you are interfacing the S-Link™ bus by agreement with Sleipner through a designated
Sleipner supplied interface, you are still required to install at least one original Sleipner control panel to enable efficient troubleshooting if necessary.
MC_0105
SLEIPNER MOTOR AS
P.O. Box 519
N-1612 Fredrikstad
Norway
www.sleipnergroup.com
DOCUMENT ID:
REVISION:
DATE:
LANGUAGE:
Installation Guide
The installer must read this document to ensure necessary familiarity with the product before installation.
Instructions in this document cannot be guaranteed to comply with all international and national regulations. It is the responsibility of the
installer to follow all applicable international and national regulations when installing Sleipner products.
The recommendations given in this document are guidelines ONLY, and Sleipner strongly recommends that advice is obtained from a person
familiar with the particular vessel and applicable regulations.
This document contains general installation instructions intended to support experienced installers. If you are not skilled in this type of work,
please contact professional installers for assistance.
If required by local regulation, electrical work must be done by a licensed professional.
Appropriate health and safety procedures must be followed during installation.
Faulty installation of Sleipner products will render all warranties given by Sleipner Motor AS.
Ensure appropriate access to Sleipner products during installation planning for service, inspection and component replacement.
MC_0038
Responsibility of the Installer
Failure to follow the considerations and precautions can cause serious injury, damage and will render all
warranties given by Sleipner Motor as VOID.
MC_0411
MC_0440
General Installation Consideration and Precaution Guidelines
