PJC 221 & 222
SRC-3 Fault Codes
MC_0636
Fault Code Fault Name Fault Description Action
100.0.0 System Error - - System Error Contact Sleipner Dealer
153.0.151 Supply Voltage - Self-Test Fault Failed to determine voltage level of the system / Out of range.
Verify that the correct battery was chosen for this system and that
it is properly charged.
10600.0.101 Retract Controller - Bus Off Actuator CAN experienced Bus Off/Bus error. Verify CAN cables to the actuators are correctly connected.
10600.0.210 Retract Controller - Service Mode In Service Mode. Exit service mode by using button controls.
10602.0.22 Retract Motion OUT Fault - Out of position
Lift or Lock Actuators went past their expected end-position
when hatch deploying.
Verify the mechanical shape of the hatch is according to specifi ca-
tion. Check fault specifi c for more info.
10602.0.51 Retract Motion OUT Fault - Current High Blocked while deploying hatch. Find and remove cause of mechanical blockage.
10603.0.22 Retract Motion IN Fault - Out of position
Lift or Lock Actuators went past their expected end-position
when hatch retracting.
Verify the mechanical shape of the hatch is according to specifi ca-
tion. Check fault specifi c for more info.
10603.0.51 Retract Motion IN Fault - Current High Blocked while retracting hatch. Find and remove cause of mechanical blockage.
10605.1.24 Lift Actuator Instance 1 Fault Lift Actuator 1 Reported a Fatal Error, could be broken. Contact Sleipner Dealer.
10605.1.53 Lift Actuator Instance 1 Overvoltage Lift Actuator 1 Measured Overvoltage Verify that the correct battery was chosen for this system.
10605.1.54 Lift Actuator Instance 1 Undervoltage Lift Actuator 1 Measured Undervoltage Verify that battery is charged.
10605.1.55 Lift Actuator Instance 1 Overtemp Lift Actuator 1 Temperature Exceeding >85C Find and eliminate cause of high temperature.
10605.1.100 Lift Actuator Instance 1 No Communication Lift Actuator 1 Not Communicating
Verify that CAN and supply cables are correctly connected, and that
no fuses have gone out.
10605.1.209 Lift Actuator Instance 1 MOTION FAULT
Lift Actuator 1 experienced linear motion while it was
supposed to be in a fi xed position. Load might have caused
backdrive.
Look for mechanical obstruction/causes for the backdrive and
remove them.
10605.2.24 Lift Actuator Instance 2 Fault Lift Actuator 2 Reported a Fatal Error, could be broken. Contact Sleipner Dealer.
10605.2.53 Lift Actuator Instance 2 Overvoltage Lift Actuator 2 Measured Overvoltage Verify that the correct battery was chosen for this system.
10605.2.54 Lift Actuator Instance 2 Undervoltage Lift Actuator 2 Measured Undervoltage Verify that battery is charged.
10605.2.55 Lift Actuator Instance 2 Overtemp Lift Actuator 2 Temperature Exceeding >85C Find and eliminate cause of high temperature.
10605.2.100 Lift Actuator Instance 2 No Communication Lift Actuator 2 Not Communicating
Verify that CAN and supply cables are correctly connected, and that
no fuses have gone out.
10605.2.209 Lift Actuator Instance 2 MOTION FAULT
Lift Actuator 2 experienced linear motion while it was
supposed to be in a fi xed position. Load might have caused
backdrive.
Look for mechanical obstruction/causes for the backdrive and
remove them.
10606.1.24 Lock Actuator Instance 1 Fault Lock Actuator 1 Reported a Fatal Error, could be broken. Contact Sleipner Dealer.
10606.1.53 Lock Actuator Instance 1 Overvoltage Lock Actuator 1 Measured Overvoltage Verify that the correct battery was chosen for this system.
10606.1.54 Lock Actuator Instance 1 Undervoltage Lock Actuator 1 Measured Undervoltage Verify that battery is charged.
10606.1.55 Lock Actuator Instance 1 Overtemp Lock Actuator 1 Temperature Exceeding >85C Find and eliminate cause of high temperature.
10606.1.100 Lock Actuator Instance 1 No Communication Lock Actuator 1 Not Communicating
Verify that CAN and supply cables are correctly connected, and that
no fuses have gone out.
10606.1.209 Lock Actuator Instance 1 MOTION FAULT
Lock Actuator 1 experienced linear motion while it was
supposed to be in a fi xed position. Load might have caused
backdrive.
Look for mechanical obstruction/causes for the backdrive and
remove them.
10607.0.209 Actuator Alignment Fault - MOTION FAULT
There was a position discrepancy between the lift actuators,
but alignment failed.
Look for mechanical obstruction/causes for alignment failure.
40008.0.206 SCU Sensor board fault 6 - WRITE FAIL EEPROM failed to write. Contact Sleipner Dealer.
When installing an S-Link™ system connect ONLY original Sleipner S-Link™ products or other authorized control equipment directly to the S-Link™ bus.
Connecting non-authorized third-party equipment, it must always be connected through a Sleipner supplied interface product.
Any attempt to directly control or connect into the S-Link™ control system without a designated and approved interface will render all warranties and
responsibilities of all of the connected Sleipner products. If you are interfacing the S-Link™ bus by agreement with Sleipner through a designated
Sleipner supplied interface, you are still required to install at least one original Sleipner control panel to enable efficient troubleshooting if necessary.
