PJC 221 & 222
PHC-3 Fault Codes
MC_0117
Fault Code Fault Name Fault Description Action
106.202.0 Emergency Stop Bow - Bow emergency stop is button activated -Release bow emergency stop
106.203.0 Emergency Stop Bow Starboard - Bow Starboard emergency stop is button activated -Release bow starboard emergency stop
106.204.0 Emergency Stop Bow Port - Bow Port emergency stop is button activated -Release bow port emergency stop
106.205.0 Emergency Stop Stern - Stern emergency stop is button activated -Release stern emergency stop
106.206.0 Emergency Stop Stern Starboard - Stern Starboard emergency stop is button activated -Release stern starboard emergency stop
106.207.0 Emergency Stop Stern Port - Stern Port emergency stop is button activated -Release stern port emergency stop
10500.0.10 PHC Oil Level - Level Low Hydraulic oil level is low
-Limit use of thruster
-Inspect hydraulic oil level
-Check system for leaks and refi ll hydraulic oil
10500.0.13 PHC Oil Level - Open Circuit Analog oil level sensor open circuit
-Sensor not connected or wire break.
-Verify sensor type in parameter 0201
-Disconnect sensor and measure that sensor resistance value is in
range 0-180ohm.
10501.0.11 PHC Oil Temp - Level High Oil temperature higher than 75°C (167°F)
-Limit use of thruster to prevent temperature to rise.
-Check if cooling pump is running and there is cooling water flow.
-Inspect seawater fi lter
-Verify that cooling pump is enabled in parameter 0301
10501.0.13 PHC Oil Temp - Open Circuit Analog oil temp sensor open circuit
-Sensor not connected or wire break.
- Disconnect sensor and measure that sensor resistance value is in
range 104ohm-147Kohm
-Wrong sensor is defi ned in parameter 0201
10501.0.16 PHC Oil Temp - Short Circuit Analog oil temp input short circuit
-Input shorted to GND, check wiring/sensor
-Disconnect sensor and measure that sensor resistance value is in
range 104ohm-147Kohm
10501.0.55 PHC Oil Temp - Overtemp
Hydraulic oil temperature has been higher than 120°C
(248°F).
-Wait for oil temperature to cool down.
-Check oil level and refi ll if level is low.
-Check if cooling pump is running.
-Check if cooling system gets water
10502.0.13 PHC Stabilizer Pressure - Open Circuit Stabilizer pressure sensor open circuit
-Sensor not connected or wire break.
-System incorrectly confi gured with stabilizer, parameter 1001
-Replace sensor
10502.0.16 PHC Stabilizer Pressure - Short Circuit Stabilizer pressure sensor short circuit
-Wires shorted or sensor defective, check wiring/sensor
-Replace sensor
10502.0.19 PHC Stabilizer Pressure - Under Limit Stabilizer pressure has dropped below 20bar.
-Check accumulator charge pressure
-Check PTO pressure (if PTO powered)
-Check system for oil leaks
-Check generator power supply to the VFD (is VFD motor speed
maximum when pressure alarming low)
10502.0.20 PHC Stabilizer Pressure - Over Limit
Stabilizer pressure is higher than:
parameter 1013 PTO OVER-PRESSURE FAULT LEVEL running
from PTO (FW V1.029 an older, set point + 30bar running
from PTO)
or set point + 15bar running from AC motor
-Check Parameter 1013 PTO OVER-PRESSURE FAULT LEVEL
-Check PTO pressure setting
-Check accumulator charge pressure
-Check unload valve operation
10502.0.26 PHC Stabilizer Pressure - VALUE MAX Stabilizer pressure reached sensor max value.
-Check that correct sensor is fi tted
-Check that sensor range parameter 1010 match the sensor
-Check PTO pressure setting
10502.0.200 PHC Stabilizer Pressure - Timeout
Stabilizer pressure has not reached 60% of set point parame-
ter 1003 after 30sec.
-Check pump feed shutoff valve.
-Check PTO pressure (if PTO powered)
-Check system for oil leaks
10503.0.13 PHC System Pressure - Open Circuit System pressure sensor open circuit
-Sensor not connected or wire break.
-Verify system pressure, parameter 0104
10503.0.16 PHC System Pressure - Short Circuit System pressure sensor short circuit
-Wires shorted or sensor defective, check wiring/sensor
-Replace sensor
10504.0.13 PHC AI 1 - Open Circuit Analog Input 1 (4-20mA) sensor open circuit -Sensor not connected or wire break.
10504.0.16 PHC AI 1 - Short Circuit Analog Input 1 (4-20mA) sensor short circuit
-Wires shorted or sensor defective, check wiring/sensor
-Replace sensor
10505.0.13 PHC AI 2 - Open Circuit Analog Input 2 (4-20mA) sensor open circuit -Sensor not connected or wire break.
PHC-3 Fault Codes
MC_0117
Fault Code Fault Name Fault Description Action
10505.0.16 PHC AI 2 - Short Circuit Analog Input 2 (4-20mA) sensor short circuit
-Wires shorted or sensor defective, check wiring/sensor
-Replace sensor
10508.0.13 PHC DOUT AC PUMP UNLOAD - Open Circuit AC Pump Unload valve open circuit
-Check for open circuit, power consumption < 5.0 Watt
-System incorrectly confi gured with stabilizer, parameter 1001
10508.0.51 PHC DOUT AC PUMP UNLOAD - Current High AC Pump Unload valve current higher than 4.0A -Check wires and connections for short circuit
10509.0.13
PHC DOUT ACCUMULATOR DUMP - Open
Circuit
Accumulator Dump valve open circuit
-Check for open circuit, power < 5.0 Watt
-System incorrectly confi gured with stabilizer, parameter 1001
10509.0.51
PHC DOUT ACCUMULATOR DUMP - Current
High
Accumulator Dump valve current higher than 4.0A -Check wires and connections for short circuit
10510.0.13 PHC DOUT STABILIZER - Open Circuit Stabilizer valve open circuit
-Check for open circuit, power consumption < 5.0 Watt
-System incorrectly confi gured with stabilizer, parameter 1001
10510.0.51 PHC DOUT STABILIZER - Current High Stabilizer valve current higher than 4.0A -Check wires and connections for short circuit
10511.0.13
PHC DOUT COOLING PUMP HYDRAULIC -
Open Circuit
Hydraulic Cooling Pump valve open circuit
-Check for open circuit, power consumption < 5.0 Watt
-Wrong cooling pump confi gured, parameter 0301
10511.0.51
PHC DOUT COOLING PUMP HYDRAULIC -
Current High
Hydraulic Cooling Pump valve current higher than 4.0A -Check wires and connections for short circuit
10512.0.13 PHC DOUT LS DUMP - Open Circuit LS-Dump valve open circuit
-Check for open circuit, power consumption < 5.0 Watt
-System wrong confi gured with thrusters, parameter 2001 or 2101
10512.0.51 PHC DOUT LS DUMP - Current High LS-Dump valve current higher than 4.0A -Check wires and connections for short circuit
10513.0.51 PHC DOUT PUMP #2 - Current High Pump #2 valve current higher than 4.0A -Check wires and connections for short circuit
10514.0.13 PHC DOUT 5 - Open Circuit
Digital Output 5 is confi gured as crossover and output is open
circuit
-Check for open circuit, power consumption < 5.0 Watt
-Output confi gured wrong, parameter 0505
10514.0.51 PHC DOUT 5 - Current High Digital Output 5 current higher than 4.0A -Check wires and connections for short circuit
10515.0.13 PHC DOUT 6 - Open Circuit
Digital Output 6 is confi gured as crossover and output is open
circuit
-Check for open circuit, power consumption < 5.0 Watt
-Output confi gured wrong, parameter 0506
10515.0.51 PHC DOUT 6 - Current High Digital Output 6 current higher than 4.0A -Check wires and connections for short circuit
10516.0.13 PHC DOUT 3 - Open Circuit
Digital Output 3 is confi gured as crossover and output is open
circuit
-Check for open circuit, power consumption < 5.0 Watt
-Output confi gured wrong, parameter 0503
10516.0.51 PHC DOUT 3 - Current High Digital Output 3 current higher than 4.0A -Check wires and connections for short circuit
10517.0.13 PHC DOUT 2 - Open Circuit
Digital Output 2 is confi gured as crossover and output is open
circuit
-Check for open circuit, power consumption < 5.0 Watt
-Output confi gured wrong, parameter 0502
10517.0.51 PHC DOUT 2 - Current High Digital Output 2 current higher than 4.0A -Check wires and connections for short circuit
10518.0.13 PHC DOUT 1 - Open Circuit
Digital Output 1 is confi gured as crossover and output is open
circuit
-Check for open circuit, power consumption < 5.0 Watt
-Output confi gured wrong, parameter 0501
10518.0.51 PHC DOUT 1 - Current High Digital Output 1 current higher than 4.0A -Check wires and connections for short circuit
10519.0.13 PHC DOUT 4 - Open Circuit
Digital Output 4 is confi gured as crossover and output is open
circuit
-Check for open circuit, power consumption < 5.0 Watt
-Output confi gured wrong, parameter 0504
10519.0.51 PHC DOUT 4 - Current High Digital Output 4 current higher than 4.0A -Check wires and connections for short circuit
10520.0.51 PHC ECI PUMP POWER FEED - Current High ECI cooling pump power current higher than 8.0A
-Check pump cable for damage and short circuits
-Make sure the connector on the cooling pump is correct inserted.
-Replace cooling pump
10521.0.51 PHC Bow Thruster Power - Current High Bow thruster PVG feed current higher than 3.0A -Check PVG wires and connections for short circuit
10522.0.51 PHC Stern Thruster Power - Current High Stern thruster PVG feed current higher than 3.0A -Check PVG wires and connections for short circuit
10523.0.51 PHC Thruster Power - Current High Bow or Stern PVG feed current higher than 3.3A Check all bow and stern PVG signal wires for short circuits
10524.0.51 PHC ECI Cooling Pump - Current High ECI cooling pump current higher than 13.0A
-Check ECI cooling pump cable for damage and short circuits
-Replace ECI cooling pump
10524.0.53 PHC ECI Cooling Pump - Overvoltage ECI cooling pump overvoltage, voltage higher than 33.0V
-Check PHC-3 input voltage is below 33.0V
-Replace ECI cooling pump
10524.0.54 PHC ECI Cooling Pump - Undervoltage ECI cooling pump under voltage, voltage is lower than 18.0V
-Check PHC-3 input voltage is higher than 18.0V
-Replace ECI cooling pump
10524.0.55 PHC ECI Cooling Pump - Overtemp ECI cooling pump temperature higher than 100°C (212°F).
-Check ECI cooling pump for damages
-Replace ECI cooling pump
