Chapter 3
Connecting your interactive whiteboard to your computer
smarttech.com/kb/001414 33
Default
manufacturing
orientation
When your interactive whiteboard uses the default manufacturing orientation data, the
touch point on the screen corresponds fairly well to the projected computer desktop
image, provided that the projected image fills the entire interactive screen. The default
orientation is a simple 2-point orientation, which might result in the projected touch point
being offset from the actual contact location. Increase the accuracy of your touch by
performing a 9-, 12- or 20-point orientation.
NOTE
You can restore the default orientation parameters by holding the Reset button on the
controller module for at least three seconds.
4- and 9-point
user
orientation
When you perform a quick 4-point or the standard 9-point orientation, the orientation
data is saved in your interactive whiteboard controller module’s flash memory (that is,
the orientation data stays with your interactive whiteboard). If you connect a different
computer, the orientation data for your interactive whiteboard remains unchanged.
12- or 20-point
user
orientation
You can also perform a 12- or 20-point user orientation. Unlike the 4- and 9-point
orientations, the drivers save the 12- and 20-point orientation data on your computer, so
it stays with your computer instead of your interactive whiteboard. Resetting the
controller module doesn’t clear the 12- or 20-point orientation data from your computer.
If you attach a different computer, your interactive whiteboard uses the highest level of
orientation data in the controller’s memory.
To orient your interactive whiteboard
1. Press and hold the two large pen tray buttons at the same time.
OR
Press the Help button on the pen tray, and then select Orient/Align the SMART Product.
NOTE
For more information on the pen tray buttons, see Pen tray buttons on page40.
The orientation screen opens.
2. Pick up a pen from the pen tray.
