Smartgen APC615 User Manual

APC615 Pump Unit Controller User Manual
APC615 Pump Unit Controller Version 1.0 2017-10-20 Page 30 of 54
No.
Type
Description
66
Diesel Driven Pump Stop
When suction pump type set as “D-driven Suction Pump”,
“Diesel Driven Pump Stop” output.
67
Electric Driven Pump Start
When suction pump type set as “E-driven Suction Pump”, it is
output when electric driven suction pump starts and stops
output when electric driven suction pump closes down.
68
Reserved
69
Digital Input 1 Active
Action when input port 1 is active.
70
Digital Input 2 Active
Action when input port 2 is active.
71
Digital Input 3 Active
Action when input port 3 is active.
72
Digital Input 4 Active
Action when input port 4 is active.
73
Digital Input 5 Active
Action when input port 5 is active.
74~98
Reserved
99
Emergency Stop
Action when emergency stop alarms occur.
100
Fail To Start
Action when failed start alarms occur.
101
Fail To Stop
Action when failed stop alarms occur.
102
Engine Under Speed
Warning
Action when under speed alarms occur
103
Engine Under Speed
Shutdown
Action when under speed shutdown alarms occur.
104
Engine Over Speed
Warning
Action when over speed warning alarms occur.
105
Engine Over Speed
Shutdown
Action when over speed shutdown alarms occur.
106~135
Reserved
136
Bypass Valve Control
137
Reserved
138
Reserved
139
Engine High Temp Warn
Action when high temperature warning alarms occur.
140
Engine Low Temp Warn
Action when low temperature warning alarms occur.
141
Engine High Temp
Shutdown
Action when hi-temperature Shutdown alarms occur.
142
Reserved
143
Engine Low Fuel Level
Warning
Action when low fuel level warning alarms occur.
144
Reserved
145
Reserved
146
Reserved
147
Engine Low Oil Pressure
Warning
Action when low oil pressure warning alarms occur.
148
Engine Low Oil Pressure
Shutdown
Action when low oil pressure shutdown alarms occur.
149
Engine Oil pressure Open
Circuit
Action when low oil pressure sensor is open circuit.
150
Reserved
