APC615 Pump Unit Controller User Manual
APC615 Pump Unit Controller Version 1.0 2017-10-20 Page 29 of 54
Action while genset is starting and disconnect while waiting for
stop.
Used for engine which has idles. It closes before starting and
opens when enters into warming up status; and it closes during
stopping idle process and opens when genset stopped
completely.
For other status, if idle input is active or idle button been
pressed, relay will close and output.
Action in warming up delay, and in normal running process, it is
controlled by GOV.
Action between the period from “stop idle” to “wait for stop” and
in normal running process, it is controlled by GOV.
Used for engines with ETS electromagnet. Close when stop
idle is over and open when pre-set “ETS delay” is over.
Suitable for engines which fitted with ECU; used for control
ECU stop.
Suitable for engines which fitted with ECU; used for control
ECU power supply.
Close when detects a successful start signal.
Close when detects unit is normal running.
Action when pump unit common warning and common
shutdown alarms occur.
Action when common shutdown alarms occur.
Action when common warning alarms occur.
Action when battery over voltage warning alarms occur.
Action when battery low voltage warning alarms occur.
Action when charge failure warning alarms occur.
Indicate ECU sends a warning signal.
Indicate ECU sends a shutdown signal.
Indicate controller cannot communicate with ECU.
When suction pump type set as “D-driven Suction Pump”,
“Diesel Driven Pump Start” output.
