HAT530 ATS CONTROLLER
HAT530 ATS CONTROLLER 2014-06-23 Version 1.0 Page 10 of 26
5 PANEL BUTTON OPERATION
Pressing and holding the button for more than 3s, all LEDs are illuminated to enter into
lamp test mode; under this mode, the controller will back to normal status automatically
after release the button.
Pressing and holding the button for more than 7s, all LEDs are flashing (500ms per
time) to enter into parameter setting status, users can set the parameters after release the
button. If users don’t want to set the parameters under this status: 1) Pressing and
holding the button again until all LEDs are flashing 5 times rapidly (200ms per time)
which means the controller enter into normal status; 2) Or the controller will back to normal
status automatically about 90s later.
