HAT530 ATS CONTROLLER
HAT530 ATS CONTROLLER 2014-06-23 Version 1.0 Page 13 of 26
5.3 DELAY ADJUSTMENT
Delay value can be set only when the controller is in parameters setting status.
Adjusting 1# normal” potentiometer (locate nearby the back panel terminal) can set
output delay after 1# power supply is normal.
Adjusting 2# normal” potentiometer (locate nearby the back panel terminal) can set
output delay after 2# power supply is normal.
Setting Procedures of “1# power abnormal delay” and 2# power abnormal delay”:
a) Press and at the same time, when 1#/2# power indicator and auto indicator are
illuminated; release the two buttons, then the auto indicator and 1#/2# power
indicators are extinguished simultaneously which means the delay timer of the
controller can be set.
1# power abnormal delay: adjust “1# Normal” potentiometer;
2# power abnormal delay: adjust “2# Normal” potentiometer;
b) After adjusting the delays, press . When 1#/2# power indicator and automatic
indicator are illuminated simultaneously, the adjusted value has been saved. The
controller will back to normal status automatically after all LEDs are flashing 5 times
rapidly and controller will work according to the set delay values.
NOTE1# Normal Delay set value must be no less than 1# Abnormal Delay, otherwise,
1# Normal Delay set value will be forced set as 1# Abnormal Delay set value.
The matters need attention of 2# is same as 1#.
