HAT530 ATS CONTROLLER
HAT530 ATS CONTROLLER 2014-06-23 Version 1.0 Page 5 of 26
1 OVERVIEW
The powerful Microprocessor contained within the HAT530 ATS controller allows for
precision voltage (2-way 3-phase/single phase) measuring and make accurate judgment on
abnormal voltage (power lost, over/under voltage, over/under frequency, loss of phase,
phase sequence wrong) and control ATS to transfer after the delay has expired. This
controller is suitable for NO Breaking ATS and ONE Breaking ATS. When #1 power is
abnormal, the controller will send signal to start genset after the “#1 abnormal delay” has
expired. “Three remote” (remote control, remote measurement and remote communication)
function can be implemented with the help of LINK communication port.
