Smartgen HAT530 User Manual

HAT530 ATS CONTROLLER
HAT530 ATS CONTROLLER 2014-06-23 Version 1.0 Page 8 of 26
3 SPECIFICATION
Items
Contents
Operating Voltage
AC170V~277V during AC power L1N1/L2N2 supply.
Power Consumption
<3W (Standby mode: <1W)
AC Voltage Input
3P4W (ph-N)
1P2W (ph-N)
2P3W (ph-N)
AC170V~AC277V(ph-N)
AC170V~AC277V (ph-N)
AC170V~AC277V(ph-N)
Rated Frequency
50/60Hz
1# Close Relay Output
5A AC250V Volts free output
2# Close Relay Output
5A AC250V Volts free output
Open Relay Output
5A AC250V Volts free output
AUX.OUTPUT 1
16A AC250V Volts free output
AUX.OUTPUT 2
16A AC250V Volts free output
Gen Start Relay
7A AC250V Volts free output
1# Close Input
COM2 connect is active.
2# Close Input
COM2 connect is active.
Forced Open Input
COM2 connect is active.
Communication
LINK interface, MODBUS Protocol
Case Dimensions
139mmx120mmx48mm
Panel Cutout
130mmx111mm
Working Conditions
Temperature: (-25~+70)°C;
Humidity: (20~93)%RH
Storage Condition
Temperature: (-25~+70)°C
Protection Level
IP55 Gasket
Insulation Strength
Apply AC2.2kV voltage between high voltage terminal and low
voltage terminal;
The leakage current is not more than 3mA within 1min.
Weight
0.51kg
