HAT530 ATS CONTROLLER
HAT530 ATS CONTROLLER 2014-06-23 Version 1.0 Page 21 of 26
NO.
Items
Description
Remark
17
1# Close Input
Detection of 1# ATS closing
status; auxiliary contact input
Connect COM2 is active.
18
2# Close Input
Detection of 2# ATS closing
status; auxiliary contact input
Connect COM2 is active.
19
Force Open
When active, the ATS is in
Neutral Position.
Connect COM2 is active.
20
COM2
Input COM
COM2
21
A2
2# AC 3-phase 4 wire voltage
input
For single phase, only
connect A2, N2.
22
B2
23
C2
24
N2
LINK
Communication
Port
Communicate with
PC/Program update
