Smartgen HGM4100LT

HGM4100LT GENSET CONTROLLER USER MANUAL
HGM4100LT Genset Controller 2019-01-28 Version1.0 Page 22 of 48
No
Items
Range
Default
Description
and not shutdown of the generator.
26
Flexible Sensor
Values
(80-140)ºC
(0-400)kPa
(0-100)%
98
The values correspond to the function settings
of 23 (Temperature sensor), 24 (Oil pressure
sensor) and 25 (Level sensor) respectively.
27
Loss of Speed
Signal Delay
(0-20.0)s
5.0
Shutdown delay of loss of speed signal; If the
set value is 0, it is only warning and not
shutdown.
28
Voltage Difference
of Charge Alt
Failure
(0-30)V
6.0
During the normal running process, when the
voltage difference between alternator D+(WL)
and B+ exceeds the set value and remains for
5s, It will initiate a “charge alt failure” shutdown
alarm signal.
29
Battery Over
Voltage
(12-40)V
33.0
When battery voltage has exceeds the set value
and remains for 20s, It will initiate a warning
alarm signal. It is only warning and not
shutdown.
30
Battery Under
Voltage
(4-30)V
8.0
When battery voltage goes under the set value
and remains for 20s, It will initiate a warning
alarm signal. It is only warning and not
shutdown.
31
CT Ratio
(5-6000)/5
500
The ratio of external CT;
32
Full Load Rating
(5-6000)A
500
Generator’s rated current; it is used for over
current loading calculation.
33
Over Current
Percentage
(50-130)%
120
When the load current has exceeded the set
value, “over current delay” is initiated.
34
Over Current
Delay
(0-3600)s
30
When load current has exceeded the set value
and the “over current” delay has expired, over
current alarm is initiated. When the set value is
0, it is only warning and not shutdown.
35
Fuel Pump On
(0-100)%
25
When fuel level has fallen below the set value
for 10s, “Fuel Pump On” signal outputs;
36
Fuel Pump Off
(0-100)%
80
When fuel level has exceeded the set value for
10s, “Fuel Pump Off” signal outputs;
37
Relay Output 1
(0-31)
6
Factory default: Reserved; For details please
see Table 8.
38
Relay Output 2
(0-31)
2
Factory default: ETS control; For details please
see Table 8.
39
Relay Output 3
(0-31)
3
Factory default: Idling speed control; For details
please see Table 8.
40
Relay Output 4
(0-31)
5
Factory default: Gen breaker close; For details
please see Table 8.
41
Relay Output 5
(0-31)
14
Factory default: Fuel relay output; For details
please see Table 8.
42
Digital Input 1
(0-31)
1
Factory default: High Temperature Alarm input;
For details please see Table 9.
43
Digital Input 1
Active
(0-1)
0
Factory default: Active when it is closed;
44
Digital Input 1
Delay
(0-20.0)s
2.0
