HGM4100LT GENSET CONTROLLER USER MANUAL
HGM4100LT Genset Controller 2019-01-28 Version1.0 Page 23 of 48
No
Items
Range
Default
Description
45
Digital Input 2
(0-31)
2
Factory default: Low Oil Pressure Alarm input.
For details please see Table 9.
46
Digital Input 2
Active
(0-1)
0
Factory default: active when it is closed;
47
Digital Input 2
Delay
(0-20.0)s
2.0
48
Digital Input 3
(0-31)
10
Factory default: Remote Start input; for details
please see Table 9.
49
Digital Input 3
Active
(0-1)
0
Factory default: Active when it is closed;
50
Digital Input 3
Delay
(0-20.0)s
2.0
51
Digital Input 4
(0-31)
11
Factory default: Low Fuel Level Warning input;
For details please see Table 9.
52
Digital Input 4
Active
(0-1)
0
Factory default: Active when it is closed;
53
Digital Input 4
Delay
(0-20.0)s
2.0
54
Digital Input 5
(0-31)
12
Factory default: Low Coolant Level Warning
input. For details please see Table 9.
55
Digital Input 5
Active
(0-1)
0
Factory default: Active when it is closed;
56
Digital Input 5
Delay
(0-20.0)s
2.0
57
Power On Mode
(0-2)
0
0: Stop Mode 1: Manual Mode 2: Auto Mode
58
Module Address
(1-254)
1
Communication address of controller;
59
Password Setting
(0-9999)
0318
For details please see NOTE 6.
60
Crank
Disconnection
Conditions
(0-6)
2
Conditions for successful start of starter; they
are Generating, Speed and Oil pressure. Their
aim is to make the motor disconnect with the
engine as soon as possible.
61
Engine Speed at
successful start
(0-6000)r/min
360
When engine speed is higher than the set
value, the starter will be disconnected.
62
Generator Freq. at
successful start
(10.0-30.0)Hz
14.0
When generator frequency is higher than the
set value, the starter will be disconnected.
63
Oil Pressure at
successful start
(0-400)kPa
200
When generator oil pressure is higher than the
set value, the starter will be disconnected.
64
High Temperature
Inhibit
(0-1)
0
Factory default: when high temperature occurs,
shutdown alarm is initiated. For function details
please see NOTE 2.
65
Low Oil Pressure
Inhibit
(0-1)
0
Factory default: when low oil pressure occurs,
shutdown alarm is initiated. For function details
please see NOTE 3.
66
Low Fuel Level
Inhibit
(0-1)
1
Factory default: when low fuel level occurs,
shutdown alarm is initiated. For function details
please see NOTE 4.
67
Flexible Sensor
Inhibit
(0-1)
1
Factory default: when configuration sensor
value is higher/lower than the set value
(particular case depends on the sensor type),
