HGM4100LT GENSET CONTROLLER USER MANUAL
HGM4100LT Genset Controller 2019-01-28 Version1.0 Page 24 of 48
No
Items
Range
Default
Description
warning alarm is initiated. For details please
see 64,65,66 Setting Items.
68
Voltage Input
(0-3)
0
0: 3P4W; 1: 2P3W; 2: 1P2W; 3: 3P3W
69
Temp. Sensor
Curve
(0-12)
8
SGX; For details please see Table 10.
70
Pressure Sensor
Curve
(0-12)
8
SGX; For details please see Table 10.
71
Multiplex Input
Liquid Level
Sensor
(0-1)
0
0: Aux. Input 4 Configuration
1: Liquid Level Sensor
For details please see NOTE 5.
72
Level Sensor
Curve
(0-7)
3
SGD; For details please see Table 10.
73
Multiplex Input
Programmable
Sensor
(0-3)
0
0: Aux. Input 5 Configuration
1: Temperature Sensor
2: Pressure Sensor
3: Liquid Level Sensor
For details please see NOTE 5.
74
Flexible Sensor
Curve
(0-9)
(0-9)
(0-5)
8
8
3
SGX;
SGX;
SGD;
75
Generator Poles
(2-64)
4
Number of generator magnetic poles; it can be
used to calculate the engine speed when speed
sensor is not installed.
76
Temp. Sensor Open
Circuit Action
(0-2)
1
0: Indication 1: Warning; 2: Shutdown
“Indication” means “+++” shall be displayed on
LCD at the position of corresponding sensor.
77
Oil Pressure Sensor
Open Circuit Action
(0-2)
1
78
Level Sensor Open
Circuit Action
(0-2)
1
79
Flexible Sensor
Open Circuit Action
(0-2)
1
80
Cooler On Set Value
(0-255)℃
60
When air cooler is configured in a output port, it
controls the open and close.
81
Cooler Off Set
Value
(0-255)℃
40
82
Low Fuel Level
Warning
(0-100)%
20
When the liquid level of the external sensor falls
below the set value, “Low Fuel Level” delay is
initiated. (this only concerns fuel level sensor
and does not concern low fuel level warning
signal via configurable input port.)
83
Gen Over Volt
Warning
(30-620)V
253
When generator voltage exceeds pre-set value,
gen over voltage warning alarm will be sent.
(No detection for over volt signal if the value is
set 620V.)
84
Gen Under Volt
Warning
(30-620)V
193
When the sample voltage is below pre-set
value, gen under voltage warning alarm will be
sent. (No detection for under volt signal if the
value is set 30V.)
