HGM4100LT GENSET CONTROLLER USER MANUAL
HGM4100LT Genset Controller 2019-01-28 Version1.0 Page 25 of 48
No
Items
Range
Default
Description
85
Gen Over Freq
Warning
(0-75.0)Hz
55.0
When generator frequency exceeds the pre-set
value, gen over frequency warning signals will
be sent.
86
Gen Under Freq
Warning
(0-75.0)Hz
42.0
When generator frequency is below the pre-set
value, gen under frequency warning signals will
be sent.
87
Gen Over Current
Warning Percentage
(50-130)%
110
When generator current exceeds the pre-set
value, gen over current warning signal will be
sent. (No warning alarm is sent if the value is
set 0.)
88
High Water Temp.
Warning
(80-300)℃
95
When the value of external temperature sensor
exceeds the pre-set value, high temperature
signal shall be sent. It is only for the
temperature sensor externally connected; No
warning alarm is sent if the value is set 300 (it is
only for temp. sensor, and the signal of digital
inputs are not included).
89
Low Oil Pressure
Warning
(0-400)kPa
124
When the value of external pressure sensor is
below the pre-set value, low oil pressure delay
starts; it only judges after end og Safe Running
delay; No warning alarm is sent if the value is
set 0 (it is only for pressure sensor, and signal
of digital inputs are not included).
90
Flexible Sensor
Warning
(80-300)ºC
(0-400)kPa
(0-100)%
95
Respectively corresponding to 88(Temperature
Sensor set), 89(Pressure Sensor set), 82(Level
Sensor set) in this table;
91
Gen Over Volt Delay
(0-20.0)s
10.0
When generator volt is higher than the pre-set
shutdown value and the “over volt” delay has
expired, then it can be considered as gen over
volt shutdown.
92
Gen Over
Frequency Delay
(0-20.0)s
2.0
When generator frequency is higher than the
pre-set shutdown value and the “over
frequency” delay has expired, then it can be
considered as gen over frequency shutdown.
93
Oil Pressure Delay
at successful start
(0-20.0)s
0.0s
When crank disconnection condition contains
oil pressure, and oil pressure of engine exceeds
the preset crank disconnection value, and the
delay has expired, then it can be considered as
genset successful start and starter will be
disconnected.
94
Scheduled Run Set
(0-1)
(0-1)
0
0
0: Enabled inhibit 1: Enabled
0: Off load 1: On load
95
Cycle Scheduled
Run Set
(0-2)
(1-31)
(0-7)
(1-23)h
(1-59)min
(0-30000)min
0
1
0
0
0
30
Cycle options: 0:monthly 1:Weekly 2:Daily
Day(Cycle options: 0: monthly active)
Week(Cycle options: 0: weekly active)
Start time(hour)
Start time(minute)
Lasting time
