HGM4100LT GENSET CONTROLLER USER MANUAL
HGM4100LT Genset Controller 2019-01-28 Version1.0 Page 26 of 48
No
Items
Range
Default
Description
96
Auto Start Inhibit Set
(0-1)
0
0: Enabled disabled 1: Enabled
97
Cycle Auto Start
Inhibit Set
(0-2)
(1-31)
(0-7)
(1-23)h
(1-59)min
(0-30000)min
0
1
0
0
0
30
Cycle options: 0:monthly 1:Weekly 2:Daily
Day(Cycle options: 0: monthly active)
Week(Cycle options: 0: weekly active)
Start prohibition time(hour)
Start prohibition time(minute)
Duration time
98
Overload Setting
(0-2)
(0-6000)kW
(0-6000)kW
(0-3600)s
0
304
290
5
0: Not used 1: Warn 2: Shutdown
Overload set value
Overload warn return value
Overload delay value
When power value exceeds preset value and
delay has expired, over power alarm is active.
Both return value and delay value can be set.
99
Date Setting
Set up controller’s date;
100
Custom Sensor
Curve Input
(0-3)
0
0: Custom temperature sensor
1: Custom pressure sensor
2: Custom fuel level sensor
3: Custom flexible sensor
Choose sensor needed to set and input
the resistance value (current/voltage) of
every point and the corresponding value
of sensor curve. 8 points are needed to
be inputted.
101
Engine Type
(0-39)
0
Conventional genset;
102
SPN Alarm Version
(1-3)
1
Alarm Version 1;
103
Manual Close
Enable Selection
(0-1)
1
0: Disabled; 1: Enabled;
When enabled, switch by pressing
button; when disabled, switch
automatically.
104
Raise Speed Pulse
Time
(0-20.0)s
0.2
Output time for speed raising pulse when
genset enters into warming up period;
105
Drop Speed Pulse
Time
(0-20.0)s
0.2
Output time for speed dropping pulse
when genset enters into stop idling
period.
NOTES:
1) If High Temperature Stop Inhibit is set in the parameter setting item, or High Temperature Stop Inhibit input is set
in the digital input port and the port is active, then when the temperature value is higher than the set high
temperature stop value, or high temperature alarm input signal is active, the controller shall only send high
temperature warning signal and not shutdown the genset;
2) If Low Oil Pressure Stop Inhibit is set in the parameter setting item, or Low Oil Pressure Stop Inhibit input is set
in the digital input port and the port is active, then when the oil pressure value is higher than the set low oil
pressure stop value, or low oil pressure alarm input signal is active, the controller shall only send low oil
pressure warning signal and not shutdown the genset;
3) If Low Level Stop Inhibit is set in the parameter setting item, or Low Level Stop Inhibit input is set in the digital
input port and the port is active, then when the fuel level value is higher than the set low level stop value, or low
