3 SPECIFICATION
Table 3 Technical Specification
Parameter
Details
Working Voltage
Range: DC8V - DC35V continuous, DC reverse connection protection
Resolution: 0.1V
Accuracy: 1%
Overall Consumption
<7W (Standby mode: ≤2.5W)
AC Voltage
Phase voltage
Range: AC15V - AC360V (ph-N)
Resolution: 0.1V
Accuracy: 0.5%
Wire voltage
Range: AC30V - AC620V (ph- ph)
Resolution: 0.1V
Accuracy: 0.5%
AC Frequency
Range: 5Hz -75Hz
Resolution: 0.01Hz
Accuracy: 0.1Hz
AC Current
Rated: 5A
Range: 0A - 10A
Resolution: 0.1A
Accuracy: 1%
Speed Sensor
Voltage Range: 1. 0V - 24V (RMS)
Frequency Range: 5Hz - 10000Hz
Charger(D+) Voltage
Range: DC0V - DC60V continuous
Resolution: 0.1V
Accuracy: 1%
Analog Sensor
Resistor Input
Range: 0Ω - 6000Ω
Resolution: 0.1
Accuracy: 1Ω (below 300Ω)
Voltage Input
Range: 0V - 5V
Resolution: 0.001V
Accuracy: 1%
Current Input
Range: 0mA - 20mA
Resolution: 0.01mA
Accuracy: 1%
Fuel Output
16A DC24V DC power supply output (relay output)
Crank Output
16A DC24V DC power supply output (relay output)
