HEC002-A/HEC006-A 6-1
6 Specifications
6.1 Specification table
The specifications of the Thermo-con is as shown below.
6-1 Specifications
Item
Spec.
Model No.
HEC002-A
HEC006-A
Operation temp. range
10.0 to 60.0 C (No dew condensation)
Indication temp. range
-9.9 - 80.0 C
Ambient environment
Temp. :10 to 35 C
Humidity : 35 to 80%RH
Environment : No corrosive gas, solvent such as thinner and flammable gas
Storage environment
Temp. :-40 to 70 C (No dew condensation and icing)
Humidity : 5 to 95%RH
Environment : No corrosive gas, solvent such as thinner and flammable gas
Accuracy related to temp.
Indication accuracy: +/- 0.2 C.
Stability: +/- 0.01 to 0.03 C (Circulating fluid OUT is directly connected with IN)
Cooling capacity
(Water)
Approx.230W
(Set temperature25C and ambient
temperature 25C)
Approx.600W
(Set temperature25C and ambient
temperature 20C)
Circulating fluid
Circulating fluid : Water
Reservoir capacity : Approx.1.2L
Pump
Max. pressure: 0.09MPa
Max. pressure: 0.1MPa
Wetted materials
SUS303, SUS304, EPDM, Ceramic, PPS glass 30%, Carbon
Polyethylene, Polyurethane
Piping port size
Circulating fluid IN/OUT : Rc1/4
Circulating fluid drain : Rc1/4
Circulating fluid IN/OUT : Rc3/8
Circulating fluid drain : Rc1/4
Power supply voltage
Single phase AC100-240V, 50/60Hz
Current consumption
8A(100V) to 3A(240V)
10A(100V) to 4A(240V)
Inrush current
50A or less
Over current protection
15A circuit protector
Insulation resistance
50M or more (DC500V, with surge absorber removed)
Acoustic noise
55dBA
65dBA
Cooling method
Air cooled
Main functions
Auto tuning, Off set, Temperature sensor fine control, Temp. upper and lower
limit alarm, Output shut off alarm, Serial communication (RS-232C)
Input operation and
indications
Membrane key sheet
LCD display panel (with back light)
Temp. sensor
Resistance thermometer sensor (Pt100, 3-wire, class A, 2mA)
(both internal sensor and external sensor)
Painting color
Urban white
Mass (at dry)
Approx.17.5kg (with feet)
Approx.27.5kg (with feet)
IP class
IP20 (IEC60529)
