Introduction
HEC002-A/HEC006-A 1-1
1 Introduction
The definition and construction of operation manual are described below.
1.1 Scope and general description of use
The operation manual applies to operation method of SMC-brand Thermo-con HEC002-A and HEC006-
A. Thermo-con is air-to-liquid heat exchanger to be used to control the temperature (e.g. detectors in an
X-Ray system). It aims easier understanding of operational and Installation information of the Thermo-
con. Before any operation and Installation of this unit, be sure to read this operation manual carefully
and understand the contents well.
This unit is Class 1 equipment with regard to the type of protection for electric shock.
1.2 Operation by external communication
It complies with communication standard RS-232C and RS-485. RS-232C can have a cable with length
up to 15m. RS-485 can have a cable with length up to 500m.
The content which can be communicated is as follows.
1) Setting and reading of target temperature
2) Reading of the value detected by temperature sensor
3) Reading of warning status
4) Setting and reading of off-set value
For operation by communication, it is necessary to order “Communication Specifications”.
<Contact>
If you have any questions or are unclear about any of the content of this manual, please contact the
following department.
SMC Corporation R&D Center
Product Development Division-6
Address: 4-2-2, KINUNODAI, TSUKUBAMIRAI-SHI, IBARAKI-KEN 300-2493, JAPAN
Phone:+81-297-52-6666
Fax:+81-297-20-5007
E-mail:kaihatsu_6_g3@smcjpn.co.jp
