Chapter 3 Transport and Setting Up
HRS-R Series 3.3 Installation
3-13
 Wiring
1. Connect the power supply cable to the secondary side of the earth leakage breaker and
grounding.
Fig. 3-7 Wiring of power supply cable(customer side)
L
N
E
Earth
Earth leakage breaker
