HRX-OM-W058
Chapter 3 Transport and Setting Up
3.3 Installation HRS-R Series
3-12
7. Plug the power supply cable in to the power cable connector on the product.
Fig. 3-6 Wiring of power supply cable(Thermo chiller side)
L
N
PE
L
N
PE
L
N
PE
For option B
