HRX-OM-O021
Chapter 5 Display and setting of various functions
5.18 Communication function HRS Series
5-70
62. Select contact output signal 3 selected alarm from the table below with [▲] key or [▼]
key, and confirm by pressing “SEL”.
Table 5.18-32 List of set value
Set value Explanation
Initial value
(Default setting)
Setting/checking are not available unless the
function setting of digial output 1 is selected
alarm status signal.
to
Sets selected alarm
Set range is AL.01 to AL.36.
63. Press the [MENU] key once.
Return to the main screen (screen displaying the circulating fluid temperature).
PV
SV
