Chapter 5 Display and setting of various functions
5.15 Alarm customize function HRS Series
5-34
5.15 Alarm customize function
5.15.1 Alarm customize function
The operation and the threshold when alarm signal is output can be
customized. Customers should set them depending on their applications.
The alarms below can be customized.
●AL01 Low level in tank (Refer to Table 5.15-3)
Operation: When this alarm signal is output, user can choose to
stop/continue the operation.
"Operation stop" is default setting.
●AL03 Circulating fluid discharge temp. rise (Refer to Table 5.15-4 and Table 5.15-5)
Operation: When this alarm signal is output, user can choose to
stop/continue operation, or not to detect this alarm.
"Operation continue" is default setting.
Threshold change: Temp. setting at which the alarm is generated can be
changed, and also, the alarm generating conditions can be set.
“45.0
o
C" is default setting.
●AL04 Circulating fluid discharge temp. (Refer to Table 5.15-6 and Table 5.15-7)
Operation: When this alarm signal is output, user can choose to
stop/continue operation, or not to detect this alarm.
"Operation continue" is default setting.
Threshold change: Temp. setting at which the alarm is generated can be
changed, and also, the alarm generating conditions can be set.
“1.0
o
C" is default setting.
●AL08 Circulating fluid discharge pressure rise (Refer to Table 5.15-8 and Table
5.15-9)
Operation: When this alarm signal is output, user can choose to
stop/continue operation, or not to detect this alarm.
"Operation continue" is default setting.
Threshold change: Pressure at which this alarm is generated can be
changed.
“0.50MPa" is default setting.
●AL09
Circulating fluid discharge pressure drop (Refer to Table 5.15-10 and Table
5.15-11)
Operation: When this alarm signal is output, user can choose to
stop/continue operation, or not to detect this alarm.
"Operation continue" is default setting.
Threshold change: Pressure at which this alarm is generated can be
changed.
“0.05MPa" is default setting.
