HRX-OM-O021
Chapter 2 Name and Function of Parts
HRS Series 2.3 Function of Parts
2-3
2.3 Function of Parts
The function of parts is as follows.
Table 2-2 Function of parts
Name Function
Operation display panel
Runs and stops the product and performs settings such as the circulating
fluid temperature.
For details, refer to ’’2.4 Operation display panel’’.
Breaker
Shuts off the power supply to the internal eqipment of product.
Breaker size 20A
(There are energized parts in the product)
Model label
Shows the part number of the product.
For details, refer to ‘’1.4.1 Product Label’’.
Circulating fluid outlet port The circulating fluid flows out from the outlet port.
Circulating fluid return port The circulating fluid returns to the return port.
Drain port This drain port to drain the circulating fluid out of the tank.
Facility water inlet
(For water-cooled type)
A facility water inlet to which the facility water is fed through piping.
The pressure of facility water should be in a range of 0.3 to 0.5MPa.
Facility water outlet
(For water-cooled type)
A facility water outlet from which the facility water returns to the user’s
machine through piping.
Automatic water-fill port
(When automatic fluid filling
[Option J] is selected.)
Piping to the automatic fluid filling port enables easy supply of the circulating
fluid through the built-in solenoid valve.The supply pressure should be in a
range of 0.2 to 0.5MPa.
Overflow port
(When automatic fluid filling
[Option J] is selected.)
This is necessary when automatic fluid filling function.Discharge excess
circulating fluid when the fluid level in the tank rises.
To Next Page
