HRX-OM-O021
Chapter 3 Transport and Setting Up
HRS Series 3.3 Installation
3-9
3.3.3 Preparation and wiring of power supply cable
Preparation
1. Remove six screws to remove the upper panel.
Fig. 3-5 Remove the upper panel
Be sure to lock out and tag out the breaker of the facility power supply
(customer power supply facility) before wiring.
The electrical facilities should be installed and wired in accordance
with local laws and regulations of each country and by a person
who has knowledge and experience.
Check the power supply. Operation with voltages, capacities and
frequencies other than the specified values can cause fire and
electrical shock.
Wire with an applicable cable size and terminal. Forcibly mounting
with an unsuitable size cable ma
eneration or fire.
Be sure to connect the power supply cable from the product side first,
and then connect the breaker of the facility power supply (the user’s
machine power supply).
When the panel is removed or mouted, be sure to wear protective
shoes and gloves to prevent injury with the edge of the panel.
To Next Page
