SMC Networks HRS050-A*-20 Series User Manual

HRX-OM-O021
Chapter 7 Control, Inspection and Cleaning
7.4 Stop for a Long Time HRS Series
7-8
9. Refer to Fig. 7-6 Plug to the piping of the product to mount the plug to the piping of the
product.
Fig. 7-6 Plug to the piping of the product
 Connection to the drain (ball valve)
When connecting piping to the drain (ball valve), fix the ball valve with a spanner.
Fig. 7-7 Connection to the drain
If you do not fix the ball valve during piping, the ball valve will rotate,
causing fluid leakage or malfunction.
Fix the ball valve durin
g
p
i
p
in
g
.
