MENTOR 12 USER’S MANUAL SECTION 2: BASIC CONTROL – Page 22
As shown in the picture, in the upper left-hand section of the screen, we can find the
controls of all the outlet sources configured (see Configuration section), the frequency
control, the chronometer or timer, several quick access command keys and the vectorial
view of the magnitudes selected.
• Different selection tabs are located on the top of the screen, providing access
exclusively to the selection and configuration of different functions that are
directly related to the Basic Control.
• The status of all the Mentor 12 inputs and outputs, both digital and analogical,
is shown on the bottom of the screen. There are also two arrows on the
bottom of the screen, which, combined with the rotary knob, enable the
desired output values to be selected, with the selected resolution. There is
also a button called “alarms” which lights up in RED whenever an operation
alarm occurs in any of the equipment outputs. A screen appears, when you
press this button, which describes the type of alarm that has occurred and the
module it corresponds to.
• The line of buttons on the right of the screen provides direct access to the
different Control Modes of Mentor 12. Apart from the access to these
modules, the Battery Simulator control can also be accessed, in order to
either select the output value or activate or deactivate the output. These
buttons and functions are always available for use from any control screen of
the equipment.
