Introduction
The PME-500-TR circuit breaker analyzer has been designed to simplify tests of contact
synchronism, coil current analysis and contact resistance measurement on medium
voltage circuit breakers, or in any case, on circuit breakers with a single contact per pole.
Its use for circuit breakers with multiple contacts per pole is not advised, although this
might occasionally be done by means of a more laborious process.
The use of the touch screen panel makes operation of the unit and data entry processes
easier and more intuitive.
The multi-pole connecting blocks have been duplicated with standard banana-type
connectors in case any of the multi-wire test leads are accidentally damaged, lost or made
unavailable in any way.
The internal battery supply makes the equipment independent from the low voltage AC
supply, not always available or close enough to the place of operation.
The contact resistance measurement is performed on the three poles at a time using the
four-wire method and with an outstanding resolution of 0.1 micro-ohms under a
measurement current of 10 A.
Please read this operation manual before using the PME-500-TR for the first time. The
support team at EuroSMC will be very pleased to answer your questions if any arise.
Congratulations for your good choice and thank you for considering EuroSMC products
and services.
EUROSMC, S.A.
Pol. Ind. P-29 Calle Buril, 69
28400 Collado Villalba
MADRID (SPAIN)
TEL: 34-91-849.89.80 / FAX: 34-91-851.25.53
sales@eurosmc.com
http://www.eurosmc.com
PME-500-TR
6
PME-500-TR packing list
1 PME-500-TR unit
1 Calibration certificate
1 Warranty statement and registration form
1 User’s Manual
1 2.5 m AC supply cord
1 trip/close coil control and current measurement test lead 5-meter
1 auxiliary inputs test lead 5-meter
1 three-phase main contact test lead 5-meter
1 three-phase resistance measurement test lead 5-meter
1 set of spare fuses
1 pair of overvoltage protective diodes
1 set of crocodile-type clamps
1 spare thermal paper roll
1 RS-232 cable for PC connection
1 EuroBreaker™ program for Windows
1 Lightweight nylon bag for protection and transport
