Raptor
92
The screen is shown below:
Exit . This closes the meter adjustment window and returns to the maintenance window.
Default values. This assigns the default values to all the meters in all the ranges, not to
the one selected.
Adjustment. This starts the adjustment process of the selected meter. Once you start to
adjust the meter, you must finish the process, at least in one range, if you have several,
because if you abort, it will be saved with incorrect values. You are only allowed to exit
the adjustment process when you finish a complete range or, if the meter only has one
range, when the entre process has been completed. The adjustment process is guided
through an assistant and only requires following the steps indicated.
Selection area of
meter to be adjusted
Proceed to
adjust
Default
values
Close meter
adjustment screen
