Raptor
96
Raptor-SL
Raptor-SL slave unit
(values @240 Vac, 50 Hz, 1 sec.turn 960 mm2, measured 25 cm on each side)
HIGH CURRENT OUTPUT
Output Current Output Voltage
No Load V (0%Imax) 0, 0.79 or 1.59 Vac - Continuous
3,8 KAac (25%Imax) 0, 0.67 or 1.34 Vac - Continuous
7,5 KAac (50%Imax) 0, 0.55 or 1.11 Vac - 3 min
15 KAac (100%Imax) 0, 0.30 or 0.61 Vac – 3 s
COMMUNICATIONS
2 IrDA interfaces Two channels for master/slaves linking
GENERAL
Supply 230 ±10%, 50/60 Hz
Weight 35 kg
Protections Protected by miniature circuit breaker
Sec. hole diameter 85 mm
Transport Wheels, folding handle, fixed handle
