Here you find controls and indicators
Display Function F
NEG HI-MAT
PLUS
color image
1
in negative image display 1-66
NEG-SEN+ current image with Superenhancement in negative image display 1-67 & -66
NEG-SEN HI-MAT
PLUS
color image
1
with Superenhancement in negative image display 1-67 & -66
NO STOP avoid automatic conveyor stop of detection functions 1-57
OBJECT FINDER activating/deactivating the object finder 1-72
O² Organic Only image 1-63
O²+ Organic Only
PLUS
image 1-63
O²-SEN Organic Only image with Superenhancement 1-67
O²+-SEN Organic Only
PLUS
image with Superenhancement 1-67
OPTI-ZOOM magnify displayed item optimally 1-72
OS Organic Stripping image 1-63
OS+ Organic Stripping
PLUS
image 1-63
OS-SEN Organic Stripping image with Superenhancement 1-67
OS+-SEN Organic Stripping
PLUS
image with Superenhancement 1-67
PRINT print current image 1-90
SEN+ current image with Superenhancement 1-67
SEN HI-MAT
PLUS
color image
1
with Superenhancement 1-67
STORE store current image 1-82
TRANSFER IMAGE transfer current image by means of the Xport system 1-51
X-ACT MENU call up X-ACT menu 1-57
X-PLORE X-PLORE image 1-67
X-PL-SEN X-PLORE image with Superenhancement 1-67
1
on the black/white monitor* you see the corresponding display for the black/white image
2 name or user identification code of the user logged in to the HI-SCAN X-ray unit (F 1-34)
3 indication of the current image display mode. The same abbreviations as under 1 are valid plus the
following:
Display Function F
VARI HI-MAT
PLUS
color image
1
is optimized for a certain absorption range 1-64
VARI... the image display mode defined after VARI (see above) is optimized for a certain ab-
sorption range
1-64
VARI-CAT1...9 HI-CAT image 1..9 with varied color-/absorption assignment 1-70
X-PLORE Z7...9 X-PLORE image at Z=7...9 1-67
X-PL Z7...9-SEN X-PLORE image at Z=7...9 with Superenhancement 1-67
1
on the black/white monitor* you see the corresponding display for the black/white image
4 display of magnification factor for the Zoom function (F 1-71)
95587412 01/01/09 © Smiths Heimann
1-24
