Wi-Fi Connection / Troubleshooting Turning Wi-Fi On and Connecting to a Network
87
13.2 Turning Wi-Fi On and Connecting to a
Network
1. From the Home screen, select Tools > Settings > Configure Wi-Fi.
Familiarize yourself with the following Wi-Fi icons located in the toolbar.
2. Select the Wi-Fi icon to turn Wi-Fi on (Figure 13-2).
Figure 13-2 Wi-Fi Icon (shown off)
3. The Wi-Fi icon will change to , indicating Wi-Fi is on.
The screen will change to display available supported network connections.
4. Select your network. Use the scroll feature to show all active connections
(Figure 13-3).
Figure 13-3 Wi-Fi Configuration Screen
1— Available Network Connections
2— Wi-Fi Icon (Wi-Fi shown on)
A password is required when choosing a secured (protected) network. Enter
the password using the on-screen keyboard and then select the check mark
on the keyboard to continue.
Networks with a proxy, challenge page, or that require the user to accept terms
of usage are not supported.
Wi-Fi performance varies depending on your wireless network equipment and
ISP.
5. Select Connect to connect to your desired network or Cancel to cancel the
request.
6. From the Connect confirmation screen select OK to continue using this
connection or Forget to disconnect this connection.
• The screen will change to display your confirmed network connection and
Snap-on Cloud registration information. For Snap-on Cloud registration
information see Snap-on Cloud on page 92.
• If the status message “Not Connected” is displayed, retry the configuration
process or see “Wi-Fi Testing” on page 88 for additional information.
Wi-Fi Icon (toggle type) Wi-Fi Test Icon
Indicates Wi-Fi is OFF
(select to turn ON)
Indicates Wi-Fi is ON
(select to turn OFF)
Select to open
Wi-Fi Test screen
Displayed on Wi-Fi configuration screen only
