BTP-P33 User’s Manual
- 8 -
For different paper width (L1), the print width(L2) and the distance from
print content to left and right edges L3 / L4) will change according to the
following table:
Paper width (L1)
Print width (L2)
Distance from
the print content
to the left
edge(L3)
Distance from
the print content
to the right
edge(L4)
80mm
72mm
4mm
4mm
60mm
58mm
1mm
1mm
44mm
42mm
1mm
1mm
2.3.2 Tear off position
L: About 8mm
