SNBC BTP-P33 - Print and Tear-off Position; Print Position Guidance

BTP-P33 User’s Manual
- 7 -
The arrow direction in the figure is the paper feeding direction.
Mark
Description
Parameters
(mm)
A
Label width
≤B
B
Liner width
80±0.5
C
Label length
10~1000
D
Label gap
2~5
//
Paper thickness
0.06-0.16
//
Liner transmittance
50%-75%
2.3 Print and tear-off position
2.3.1 Print position
Print length: Max.1000mm,Min.25mm(Label paper type)
L1: Paper width
L2: Print width
L3: Distance from the print content to the left edge
L4: Distance from the print content to the right edge
