BTP-P33 User’s Manual
- 4 -
Power adapter
Input voltage: AC100-240VAC/50～60Hz
Output voltage: 12V±0.6V DC，1A
Print head life
≥50Km(standard test conditions)
Working temperature
and humidity
Temperature: -10 ~ 50 ℃, Humidity: 10 ~ 90%,
non-condensation
Storage temperature
and humidity
Temperature: -20 ~ 60 ℃, Humidity: 10 ~ 90%,
non-condensation
Overall size
109(L)×105(W)×51(H)mm
2.2Paper specification
 Paper type: label paper, black marked paper, continuous paper,
external thermal paper roller
 Paper roll OD: Max. 40mm
 Paper roll ID: Min. 12.5mm
2.2.1 Parameters of continuous paper
Description
Parameters (mm)
Paper width
44/60/80±0.5
Paper thickness
0.06-0.10
2.2.2 Parameters of marked paper
The black marks can be on the print side or the non-print side. When the
black marks are on the print side, refer to Fig. 2.2.2-1; when the black
marks are on the non-print side, refer to Fig. 2.2.2-2.
