BTP-P33 User’s Manual
- 6 -
Mark
Description
Parameters (mm)
A
Paper width
80±0.5
B
Length of black mark
20~80(left)13~80(right)
C
Space between black marks
10~1000
D
Height of black marks
2~8
//
Paper thickness
0.06-0.10
//
Mark reflectivity
<15%
2.2.3 Parameters of label paper
Label gap: the transmission sensor (standard configuration) is located at
the centerleft position
Fig. 2.2.3-1 Label paper type
