5.2 COMMENTS CONCERNING THE MENUS
5.2.1 Menu measurements
This menu displays the following system measurements:
- general measurements of the UPS
- output power of the UPS,
- inverter and bypass measurements,
- rectifier measurements.
5.2.2 Menu UPS commands
The UPS commands menu enables (Please refer to the sections related to the menu
structure):
- the automatic start up (interactive procedure)
- the transfer from the inverter to the mains (and vice-versa),
- the transfer to the maintenance bypass (interactive procedure),
Note: in the event of a modular system, the UPS COMMANDS menu is common to all the
modules connected. The control can be performed on whatever module.
5.2.3 Menu Event log
Principle:
The UPS has a memory enabling the record and date all alarms, status or commands that
could arise during operation. This memory is saved utilising a separate supply.
The log can record up to 500 items according to the FIFO principle (First In - First out).
When the log is filled up, the latest information recorded overwrites the earliest one.
Use:
To improve the user-friendliness, the latest records of the relevant date are displayed over
six lines. Press key
or to respectively scroll up to previous line or scroll down to
next line. The "ENTER" key provides access to the previous days.
EVENT LOG
05/12/2005
15:19:45 Unit overload yes
15:19:30 Load protected by inverter yes
15:19:20 Load on automatic bypass yes
15:19:05 Inverter ON yes
15:15:35 Battery charging yes
15:15:28 Charger ON yes ↓
↓ indicates other messages are stored. Press key
to have access to the previous
information.
