socomec DIRIS A40 User Manual

DIRIS A40/A41 - RS485 - JBUS/MODBUS
®
14
DIRIS A40/A41 - Ref.: 536 103 B GB
Decimal Hex. No. of Description Unit JBUS function
address address words available
51556 C964 1 Harmonic I2 row 7 0,001 3
51557 C965 1 Harmonic I3 row 7 0,001 3
51558 C966 1 Harmonic IN row 7 0,001 3
51559 C967 1 Harmonic I1 row 9 0,001 3
51560 C968 1 Harmonic I2 row 9 0,001 3
51561 C969 1 Harmonic I3 row 9 0,001 3
51562 C96A 1 Harmonic IN row 9 0,001 3
51563 C96B 1 Harmonic I1 row 11 0,001 3
51564 C96C 1 Harmonic I2 row 11 0,001 3
51565 C96D 1 Harmonic I3 row 11 0,001 3
51566 C96E 1 Harmonic IN row 11 0,001 3
51567 C96F 1 Harmonic I1 row 13 0,001 3
51568 C970 1 Harmonic I2 row 13 0,001 3
51569 C971 1 Harmonic I3 row 13 0,001 3
51570 C972 1 Harmonic IN row 13 0,001 3
51571 C973 1 Harmonic I1 row 15 0,001 3
51572 C974 1 Harmonic I2 row 15 0,001 3
51573 C975 1 Harmonic I3 row 15 0,001 3
51574 C976 1 Harmonic IN row 15 0,001 3
51575 C977 1 Harmonic I1 row 17 0,001 3
51576 C978 1 Harmonic I2 row 17 0,001 3
51577 C979 1 Harmonic I3 row 17 0,001 3
51578 C97A 1 Harmonic IN row 17 0,001 3
51579 C97B 1 Harmonic I1 row 19 0,001 3
51580 C97C 1 Harmonic I2 row 19 0,001 3
51581 C97D 1 Harmonic I3 row 19 0,001 3
51582 C97E 1 Harmonic IN row 19 0,001 3
51583 C97F 1 Harmonic I1 row 21 0,001 3
51584 C980 1 Harmonic I2 row 21 0,001 3
51585 C981 1 Harmonic I3 row 21 0,001 3
51586 C982 1 Harmonic IN row 21 0,001 3
51587 C983 1 Harmonic I1 row 23 0,001 3
51588 C984 1 Harmonic I2 row 23 0,001 3
51589 C985 1 Harmonic I3 row 23 0,001 3
51590 C986 1 Harmonic IN row 23 0,001 3
51591 C987 1 Harmonic I1 row 25 0,001 3
51592 C988 1 Harmonic I2 row 25 0,001 3
51593 C989 1 Harmonic I3 row 25 0,001 3
51594 C98A 1 Harmonic IN row 25 0,001 3
51595 C98B 1 Harmonic I1 row 27 0,001 3
51596 C98C 1 Harmonic I2 row 27 0,001 3
51597 C98D 1 Harmonic I3 row 27 0,001 3
51598 C98E 1 Harmonic IN row 27 0,001 3
51599 C98F 1 Harmonic I1 row 29 0,001 3
51600 C990 1 Harmonic I2 row 29 0,001 3
51601 C991 1 Harmonic I3 row 29 0,001 3
51602 C992 1 Harmonic IN row 29 0,001 3
51603 C993 1 Harmonic I1 row 31 0,001 3
51604 C994 1 Harmonic I2 row 31 0,001 3
51605 C995 1 Harmonic I3 row 31 0,001 3
51606 C996 1 Harmonic IN row 31 0,001 3
51607 C997 1 Harmonic I1 row 33 0,001 3
51608 C998 1 Harmonic I2 row 33 0,001 3
51609 C999 1 Harmonic I3 row 33 0,001 3
COMMUNICATION
A : NEW COMMUNICATION TABLE FROM 01/2009
6 > TABLE C950Hex (continued)

socomec DIRIS A40 Specifications

General

Type	Multifunction Meter
Display	LCD with backlight
Operating Temperature	-10 to +55 °C
Mounting	Panel mounting
Measurement Parameters	Voltage, Current, Power, Energy, Frequency
Communication	RS485, Modbus RTU
Storage Temperature	-25°C to +70°C
Protection Degree	IP20
Standards	IEC 61557-12
Accuracy	Class 0.5
Dimensions	96 x 96 mm
