DIRIS A40/A41 - RS485 - JBUS/MODBUS
®
22
DIRIS A40/A41 - Ref.: 536 103 B GB
COMMUNICATION
LIST OF PARAMETERS TO BE DISPLAYED (FUNCTION 3)
Table of values with allocated current and voltage winf-ding ratios on 2 words
Decimal Hexa. Number Text Unit
address address of words
768 300 2 Phase 1 current mA
770 302 2 Phase 2 current mA
772 304 2 Phase 3 current mA
774 306 2 Neutral current mA
776 308 2 Phase to phase voltage U12 V/100
778 30A 2 Phase to phase voltage U23 V/100
780 30C 2 Phase to phase voltage U31 V/100
782 30E 2 Phase to neutral voltage phase 1 V/100
784 310 2 Phase to neutral voltage phase 2 V/100
786 312 2 Phase to neutral voltage phase 3 V/100
788 314 2 Frequency Hz/100
790 316 2 Σ active power +/- kW/100
792 318 2 Σ reactive power +/- kvar/100
794 31A 2 Σ apparent power kVA/100
796 31C 2 Σ power factor 0.001
-: leading and +: lagging
798 31E 2 Active power phase 1 +/- kW/100
800 320 2 Active power phase 2 +/- kW/100
802 322 2 Active power phase 3 +/- kW/100
804 324 2 Reactive power phase 1 +/- kvar/100
806 326 2 Reactive power phase 2 +/- kvar/100
808 328 2 Reactive power phase 3 +/- kvar/100
810 32A 2 Apparent power phase 1 kVA/100
812 32C 2 Apparent power phase 2 kVA/100
814 32E 2 Apparent power phase 3 kVA/100
816 330 2 Power factor phase 1
-: leading and +: lagging 0.001
818 332 2 Power factor phase 2
-: leading and +: lagging 0.001
820 334 2 Power factor phase 3
-: leading and +: lagging 0.001
822 336 2 avg I1 mA
824 338 2 avg I2 mA
826 33A 2 avg I3 mA
828 33C 2 avg Σ active power + kW/100
830 33E 2 avg Σ active power - kW/100
832 340 2 avg Σ reactive power + kvar/100
834 342 2 avg Σ reactive power - kvar/100
836 344 2 avg Σ apparent power kVA/100
838 346 2 max/avg I1 mA
840 348 2 max/avg I2 mA
842 34A 2 max/avg I3 mA
844 34C 2 max/avg Σ active power + kW/100
846 34E 2 max/avg Σ active power - kW/100
848 350 2 max/avg Σ reactive power + kvar/100
850 352 2 max/avg Σ reactive power - kvar/100
852 354 2 max/avg Σ apparent power kVA/100
854 356 2 hour meter 1/100 h
856 358 2 Active energy + kWh
858 35A 2 Reactive energy + kvarh
860 35C 2 Apparent energy kVAh
862 35E 2 Active energy - kWh
864 360 2 Reactive energy - kvarh
B : OLD COMMUNICATION TABLE BEFORE 01/2009
