DIRIS A40/A41 - RS485 - JBUS/MODBUS
®
20
DIRIS A40/A41 - Ref.: 536 103 B GB
Decimal Hex. No. of Description Unit JBUS function
address address words available
57351 E007 1 TP secondary :
60 : 60 V
100 : 100 V
110 : 110 V
115 : 115 V
120 : 120 V
173 : 173 V
190 : 190 V V 3; 6; 16
57352 E008 2 TP primary V 3; 6; 16
57354 E00A 1 Synchronisation start
0 : internal - 1 : external – 3; 6; 16
57355 E00B 1 Internal synchronisation
of mean powers P+/- Q+/- :
300 : 5mn - 480 : 8mn - 600 : 10mn
900 : 15mn - 1200 : 20mn - 1800 : 30mn s 3; 6; 16
COMMUNICATION
A : NEW COMMUNICATION TABLE FROM 01/2009
7 > TABLE E000 Hex (continued)
Decimal Hex. No. of Description Unit JBUS function
address address words available
57616 E110 1 Ethernet Adress IP Class A (0-255� – 3; 6; 16
57617 E111 1 Ethernet Adress IP Class B (0-255� – 3; 6; 16
57618 E112 1 Ethernet Adress IP Class C (0-255� – 3; 6; 16
57619 E113 1 Ethernet Adress IP Class D (0-255� – 3; 6; 16
57620 E114 1 Ethernet GATE Class A (0-255� – 3; 6; 16
57621 E115 1 Ethernet GATE Class B (0-255� – 3; 6; 16
57622 E116 1 Ethernet GATE Class C (0-255� – 3; 6; 16
57623 E117 1 Ethernet GATE Class D (0-255� – 3; 6; 16
57624 E118 1 Ethernet MASK Class A (0-255� – 3; 6; 16
57625 E119 1 Ethernet MASK Class B (0-255� – 3; 6; 16
57626 E11A 1 Ethernet MASK Class C (0-255� – 3; 6; 16
57627 E11B 1 Ethernet MASK Class D (0-255� – 3; 6; 16
57628 E11C 1 Use of DHCP
0 : No - 1 : Yes – 3; 6; 16
57629 E11D 1 Reserved for manufacturer – 3; 6; 16
57630 E11E 1 JBUS RTU over Ethernet
0 : No - 1 ; Yes – 3; 6; 16
57631 E11F 1 JBUS/MODBUS gateway speed > Ethernet
0 = 2400 bps - 1 = 4800 bps - 2 = 9600 bps
3 = 19200 bps - 4 = 38400 bps – 3; 6; 16
57632 E120 1 JBUS/MODBUS gateway parity > Ethernet
0 = none 0 = none
1 = even 1 = even
2 = odd 2 = odd
57633 E121 1 JBUS/MODBUS gateway stop bits > Ethernet - 3; 6; 16
57634 E122 1 Time out Jbus / Modbus > Ethernet 500 ms 3; 6; 16
57635 E123 1 JBUS slave address (RS485 & RTU over Ethernet� 1-247 3; 6; 16
8 > TABLE E110 Hex : Ethernet conguration
