DIRIS A40/A41 - RS485 - JBUS/MODBUS
®
GB
19
DIRIS A40/A41 - Ref.: 536 103 B GB
A : NEW COMMUNICATION TABLE FROM 01/2009
6 > TABLE C950Hex (continued)
Decimal Hex. No. of Description Unit JBUS function
address address words available
51824 CA70 1 Harmonic V2 row 41 0,001 3
51825 CA71 1 Harmonic V3 row 41 0,001 3
51826 CA72 1 Harmonic V1 row 43 0,001 3
51827 CA73 1 Harmonic V2 row 43 0,001 3
51828 CA74 1 Harmonic V3 row 43 0,001 3
51829 CA75 1 Harmonic V1 row 45 0,001 3
51830 CA76 1 Harmonic V2 row 45 0,001 3
51831 CA77 1 Harmonic V3 row 45 0,001 3
51832 CA78 1 Harmonic V1 row 47 0,001 3
51833 CA79 1 Harmonic V2 row 47 0,001 3
51834 CA7A 1 Harmonic V3 row 47 0,001 3
51835 CA7B 1 Harmonic V1 row 49 0,001 3
51836 CA7C 1 Harmonic V2 row 49 0,001 3
51837 CA7D 1 Harmonic V3 row 49 0,001 3
51838 CA7E 1 Harmonic V1 row 51 0,001 3
51839 CA7F 1 Harmonic V2 row 51 0,001 3
51840 CA80 1 Harmonic V3 row 51 0,001 3
51841 CA81 1 Harmonic V1 row 53 0,001 3
51842 CA82 1 Harmonic V2 row 53 0,001 3
51843 CA83 1 Harmonic V3 row 53 0,001 3
51844 CA84 1 Harmonic V1 row 55 0,001 3
51845 CA85 1 Harmonic V2 row 55 0,001 3
51846 CA86 1 Harmonic V3 row 55 0,001 3
51847 CA87 1 Harmonic V1 row 57 0,001 3
51848 CA88 1 Harmonic V2 row 57 0,001 3
51849 CA89 1 Harmonic V3 row 57 0,001 3
51850 CA8A 1 Harmonic V1 row 59 0,001 3
51851 CA8B 1 Harmonic V2 row 59 0,001 3
51852 CA8C 1 Harmonic V3 row 59 0,001 3
51853 CA8D 1 Harmonic V1 row 61 0,001 3
51854 CA8E 1 Harmonic V2 row 61 0,001 3
51855 CA8F 1 Harmonic V3 row 61 0,001 3
51856 CA90 1 Harmonic V1 row 63 0,001 3
51857 CA91 1 Harmonic V2 row 63 0,001 3
51858 CA92 1 Harmonic V3 row 63 0,001 3
7 > TABLE E000 Hex : Primary conguration
Decimal Hex. No. of Description Unit JBUS function
address address words available
57344 E000 1 Network type :
0 : 1BL 1 : 2BL 2 : 3BL 3 : 3NBL 4 : 4BL 5 : 4NBL – 3; 6; 16
57345 E001 1 CT secondary :
1: 1 A 5: 5 A A 3; 6; 16
57346 E002 1 CT primary A 3; 6; 16
57347 E003 1 Neutral current input on CT :
0 : No 1: Yes – 3; 6; 16
57348 E004 1 CTN secondary :
1: 1 A 5: 5 A A 3; 6; 16
57349 E005 1 CTN primary A 3; 6; 16
57350 E006 1 Voltage input on TP :
0 : No 1: Yes – 3; 6; 16
COMMUNICATION
