socomec DIRIS A40 User Manual

DIRIS A40/A41 - RS485 - JBUS/MODBUS
®
18
DIRIS A40/A41 - Ref.: 536 103 B GB
Decimal Hex. No. of Description Unit JBUS function
address address words available
51770 CA3A 1 Harmonic V2 row 5 0,001 3
51771 CA3B 1 Harmonic V3 row 5 0,001 3
51772 CA3C 1 Harmonic V1 row 7 0,001 3
51773 CA3D 1 Harmonic V2 row 7 0,001 3
51774 CA3E 1 Harmonic V3 row 7 0,001 3
51775 CA3F 1 Harmonic V1 row 9 0,001 3
51776 CA40 1 Harmonic V2 row 9 0,001 3
51777 CA41 1 Harmonic V3 row 9 0,001 3
51778 CA42 1 Harmonic V1 row 11 0,001 3
51779 CA43 1 Harmonic V2 row 11 0,001 3
51780 CA44 1 Harmonic V3 row 11 0,001 3
51781 CA45 1 Harmonic V1 row 13 0,001 3
51782 CA46 1 Harmonic V2 row 13 0,001 3
51783 CA47 1 Harmonic V3 row 13 0,001 3
51784 CA48 1 Harmonic V1 row 15 0,001 3
51785 CA49 1 Harmonic V2 row 15 0,001 3
51786 CA4A 1 Harmonic V3 row 15 0,001 3
51787 CA4B 1 Harmonic V1 row 17 0,001 3
51788 CA4C 1 Harmonic V2 row 17 0,001 3
51789 CA4D 1 Harmonic V3 row 17 0,001 3
51790 CA4E 1 Harmonic V1 row 19 0,001 3
51791 CA4F 1 Harmonic V2 row 19 0,001 3
51792 CA50 1 Harmonic V3 row 19 0,001 3
51793 CA51 1 Harmonic V1 row 21 0,001 3
51794 CA52 1 Harmonic V2 row 21 0,001 3
51795 CA53 1 Harmonic V3 row 21 0,001 3
51796 CA54 1 Harmonic V1 row 23 0,001 3
51797 CA55 1 Harmonic V2 row 23 0,001 3
51798 CA56 1 Harmonic V3 row 23 0,001 3
51799 CA57 1 Harmonic V1 row 25 0,001 3
51800 CA58 1 Harmonic V2 row 25 0,001 3
51801 CA59 1 Harmonic V3 row 25 0,001 3
51802 CA5A 1 Harmonic V1 row 27 0,001 3
51803 CA5B 1 Harmonic V2 row 27 0,001 3
51804 CA5C 1 Harmonic V3 row 27 0,001 3
51805 CA5D 1 Harmonic V1 row 29 0,001 3
51806 CA5E 1 Harmonic V2 row 29 0,001 3
51807 CA5F 1 Harmonic V3 row 29 0,001 3
51808 CA60 1 Harmonic V1 row 31 0,001 3
51809 CA61 1 Harmonic V2 row 31 0,001 3
51810 CA62 1 Harmonic V3 row 31 0,001 3
51811 CA63 1 Harmonic V1 row 33 0,001 3
51812 CA64 1 Harmonic V2 row 33 0,001 3
51813 CA65 1 Harmonic V3 row 33 0,001 3
51814 CA66 1 Harmonic V1 row 35 0,001 3
51815 CA67 1 Harmonic V2 row 35 0,001 3
51816 CA68 1 Harmonic V3 row 35 0,001 3
51817 CA69 1 Harmonic V1 row 37 0,001 3
51818 CA6A 1 Harmonic V2 row 37 0,001 3
51819 CA6B 1 Harmonic V3 row 37 0,001 3
51820 CA6C 1 Harmonic V1 row 39 0,001 3
51821 CA6D 1 Harmonic V2 row 39 0,001 3
51822 CA6E 1 Harmonic V3 row 39 0,001 3
51823 CA6F 1 Harmonic V1 row 41 0,001 3
COMMUNICATION
A : NEW COMMUNICATION TABLE FROM 01/2009
6 > TABLE C950Hex (continued)

socomec DIRIS A40 Specifications

General

Type	Multifunction Meter
Display	LCD with backlight
Operating Temperature	-10 to +55 °C
Mounting	Panel mounting
Measurement Parameters	Voltage, Current, Power, Energy, Frequency
Communication	RS485, Modbus RTU
Storage Temperature	-25°C to +70°C
Protection Degree	IP20
Standards	IEC 61557-12
Accuracy	Class 0.5
Dimensions	96 x 96 mm
