socomec DIRIS A40 User Manual

DIRIS A40/A41 - RS485 - JBUS/MODBUS
®
GB
17
DIRIS A40/A41 - Ref.: 536 103 B GB
A : NEW COMMUNICATION TABLE FROM 01/2009
6 > TABLE C950Hex (continued)
Decimal Hex. No. of Description Unit JBUS function
address address words available
51717 CA05 1 Harmonic U12 row 33 0,001 3
51718 CA06 1 Harmonic U23 row 33 0,001 3
51719 CA07 1 Harmonic U31 row 33 0,001 3
51720 CA08 1 Harmonic U12 row 35 0,001 3
51721 CA09 1 Harmonic U23 row 35 0,001 3
51722 CA0A 1 Harmonic U31 row 35 0,001 3
51723 CA0B 1 Harmonic U12 row 37 0,001 3
51724 CA0C 1 Harmonic U23 row 37 0,001 3
51725 CA0D 1 Harmonic U31 row 37 0,001 3
51726 CA0E 1 Harmonic U12 row 39 0,001 3
51727 CA0F 1 Harmonic U23 row 39 0,001 3
51728 CA10 1 Harmonic U31 row 39 0,001 3
51729 CA11 1 Harmonic U12 row 41 0,001 3
51730 CA12 1 Harmonic U23 row 41 0,001 3
51731 CA13 1 Harmonic U31 row 41 0,001 3
51732 CA14 1 Harmonic U12 row 43 0,001 3
51733 CA15 1 Harmonic U23 row 43 0,001 3
51734 CA16 1 Harmonic U31 row 43 0,001 3
51735 CA17 1 Harmonic U12 row 45 0,001 3
51736 CA18 1 Harmonic U23 row 45 0,001 3
51737 CA19 1 Harmonic U31 row 45 0,001 3
51738 CA1A 1 Harmonic U12 row 47 0,001 3
51739 CA1B 1 Harmonic U23 row 47 0,001 3
51740 CA1C 1 Harmonic U31 row 47 0,001 3
51741 CA1D 1 Harmonic U12 row 49 0,001 3
51742 CA1E 1 Harmonic U23 row 49 0,001 3
51743 CA1F 1 Harmonic U31 row 49 0,001 3
51744 CA20 1 Harmonic U12 row 51 0,001 3
51745 CA21 1 Harmonic U23 row 51 0,001 3
51746 CA22 1 Harmonic U31 row 51 0,001 3
51747 CA23 1 Harmonic U12 row 53 0,001 3
51748 CA24 1 Harmonic U23 row 53 0,001 3
51749 CA25 1 Harmonic U31 row 53 0,001 3
51750 CA26 1 Harmonic U12 row 55 0,001 3
51751 CA27 1 Harmonic U23 row 55 0,001 3
51752 CA28 1 Harmonic U31 row 55 0,001 3
51753 CA29 1 Harmonic U12 row 57 0,001 3
51754 CA2A 1 Harmonic U23 row 57 0,001 3
51755 CA2B 1 Harmonic U31 row 57 0,001 3
51756 CA2C 1 Harmonic U12 row 59 0,001 3
51757 CA2D 1 Harmonic U23 row 59 0,001 3
51758 CA2E 1 Harmonic U31 row 59 0,001 3
51759 CA2F 1 Harmonic U12 row 61 0,001 3
51760 CA30 1 Harmonic U23 row 61 0,001 3
51761 CA31 1 Harmonic U31 row 61 0,001 3
51762 CA32 1 Harmonic U12 row 63 0,001 3
51763 CA33 1 Harmonic U23 row 63 0,001 3
51764 CA34 1 Harmonic U31 row 63 0,001 3
Phase to neutral voltage
51765 CA35 1 Max rank 3
51766 CA36 1 Harmonic V1 row 3 0,001 3
51767 CA37 1 Harmonic V2 row 3 0,001 3
51768 CA38 1 Harmonic V3 row 3 0,001 3
51769 CA39 1 Harmonic V1 row 5 0,001 3
COMMUNICATION

socomec DIRIS A40 Specifications

General

Type	Multifunction Meter
Display	LCD with backlight
Operating Temperature	-10 to +55 °C
Mounting	Panel mounting
Measurement Parameters	Voltage, Current, Power, Energy, Frequency
Communication	RS485, Modbus RTU
Storage Temperature	-25°C to +70°C
Protection Degree	IP20
Standards	IEC 61557-12
Accuracy	Class 0.5
Dimensions	96 x 96 mm
