DIRIS A40/A41 - RS485 - JBUS/MODBUS
®
16
DIRIS A40/A41 - Ref.: 536 103 B GB
Decimal Hex. No. of Description Unit JBUS function
address address words available
51664 C9D0 1 Harmonic I2 row 61 0,001 3
51665 C9D1 1 Harmonic I3 row 61 0,001 3
51666 C9D2 1 Harmonic IN row 61 0,001 3
51667 C9D3 1 Harmonic I1 row 63 0,001 3
51668 C9D4 1 Harmonic I2 row 63 0,001 3
51669 C9D5 1 Harmonic I3 row 63 0,001 3
51670 C9D6 1 Harmonic IN row 63 0,001 3
Phase to phase voltage
51671 C9D7 1 Max rank 3
51672 C9D8 1 Harmonic U12 row 3 0,001 3
51673 C9D9 1 Harmonic U23 row 3 0,001 3
51674 C9DA 1 Harmonic U31 row 3 0,001 3
51675 C9DB 1 Harmonic U12 row 5 0,001 3
51676 C9DC 1 Harmonic U23 row 5 0,001 3
51677 C9DD 1 Harmonic U31 row 5 0,001 3
51678 C9DE 1 Harmonic U12 row 7 0,001 3
51679 C9DF 1 Harmonic U23 row 7 0,001 3
51680 C9E0 1 Harmonic U31 row 7 0,001 3
51681 C9E1 1 Harmonic U12 row 9 0,001 3
51682 C9E2 1 Harmonic U23 row 9 0,001 3
51683 C9E3 1 Harmonic U31 row 9 0,001 3
51684 C9E4 1 Harmonic U12 row 11 0,001 3
51685 C9E5 1 Harmonic U23 row 11 0,001 3
51686 C9E6 1 Harmonic U31 row 11 0,001 3
51687 C9E7 1 Harmonic U12 row 13 0,001 3
51688 C9E8 1 Harmonic U23 row 13 0,001 3
51689 C9E9 1 Harmonic U31 row 13 0,001 3
51690 C9EA 1 Harmonic U12 row 15 0,001 3
51691 C9EB 1 Harmonic U23 row 15 0,001 3
51692 C9EC 1 Harmonic U31 row 15 0,001 3
51693 C9ED 1 Harmonic U12 row 17 0,001 3
51694 C9EE 1 Harmonic U23 row 17 0,001 3
51695 C9EF 1 Harmonic U31 row 17 0,001 3
51696 C9F0 1 Harmonic U12 row 19 0,001 3
51697 C9F1 1 Harmonic U23 row 19 0,001 3
51698 C9F2 1 Harmonic U31 row 19 0,001 3
51699 C9F3 1 Harmonic U12 row 21 0,001 3
51700 C9F4 1 Harmonic U23 row 21 0,001 3
51701 C9F5 1 Harmonic U31 row 21 0,001 3
51702 C9F6 1 Harmonic U12 row 23 0,001 3
51703 C9F7 1 Harmonic U23 row 23 0,001 3
51704 C9F8 1 Harmonic U31 row 23 0,001 3
51705 C9F9 1 Harmonic U12 row 25 0,001 3
51706 C9FA 1 Harmonic U23 row 25 0,001 3
51707 C9FB 1 Harmonic U31 row 25 0,001 3
51708 C9FC 1 Harmonic U12 row 27 0,001 3
51709 C9FD 1 Harmonic U23 row 27 0,001 3
51710 C9FE 1 Harmonic U31 row 27 0,001 3
51711 C9FF 1 Harmonic U12 row 29 0,001 3
51712 CA00 1 Harmonic U23 row 29 0,001 3
51713 CA01 1 Harmonic U31 row 29 0,001 3
51714 CA02 1 Harmonic U12 row 31 0,001 3
51715 CA03 1 Harmonic U23 row 31 0,001 3
51716 CA04 1 Harmonic U31 row 31 0,001 3
COMMUNICATION
A : NEW COMMUNICATION TABLE FROM 01/2009
6 > TABLE C950Hex (continued)

socomec DIRIS A40 Specifications

General

Type	Multifunction Meter
Display	LCD with backlight
Operating Temperature	-10 to +55 °C
Mounting	Panel mounting
Measurement Parameters	Voltage, Current, Power, Energy, Frequency
Communication	RS485, Modbus RTU
Storage Temperature	-25°C to +70°C
Protection Degree	IP20
Standards	IEC 61557-12
Accuracy	Class 0.5
Dimensions	96 x 96 mm
