DIRIS A40/A41 - RS485 - JBUS/MODBUS
®
62
DIRIS A40/A41 - Ref.: 536 103 B GB
DATE AND HOUR SETTINGS (FUNCTION 3, 6 OR 16)
Input meters
Zone size: 6 words (decimal) or 6 (hexadecimal).
Decimal Hexa. Number Text Unit
address address of words
3072 C00 1 Day
3073 C01 1 Month
3074 C02 1 Year
3075 C03 1 Hour
3076 C04 1 Minute
3077 C05 1 Second
COMMUNICATION
Decimal Hexa. Number Text Unit
address address of words
3088 C10 1 Alarm output number (1 to 6�
3089 C11 1 Lower threshold:
0 : no alarm
1 : I1
2 : I2
3 : I3
4 : In
5 : U12
6 : U23
7 : U31
8 : ΣP+
9 : ΣQ+
10 : ΣS
11 : F
12 : ΣPFL
15 : thd I1
16 : thd I2
17 : thd I3
18 : thd U12
19 : thd U23
20 : thd U31
21 : HOUR
22 : V1
23 : V2
24 : V3
25 : thd In
26 : thd V1
27 : thd V2
28 : thd V3
29 : ΣP-
30 : ΣQ-
31 : ΣPFC
32 : T°C 1
33 : T°C 2
34 : T°C 3
35 : T°C internal
36 : ΣP predicted
37 : ΣQ predicted
38 : ΣS predicted
3090 C12 2 Lower threshold value
LAST 10 ALARMS EVENT LOG (FUNCTION 3)
Alarm n-1
