socomec DIRIS A40 User Manual

DIRIS A40/A41 - RS485 - JBUS/MODBUS
®
GB
63
DIRIS A40/A41 - Ref.: 536 103 B GB
Decimal Hexa. Number Text Unit
address address of words
3092 C14 1 Lower threshold:
0 : no alarm
1 : I1
2 : I2
3 : I3
4 : In
5 : U12
6 : U23
7 : U31
8 : ΣP+
9 : ΣQ+
10 : ΣS
11 : F
12 : ΣPFL
15 : thd I1
16 : thd I2
17 : thd I3
18 : thd U12
19 : thd U23
20 : thd U31
21 : HOUR
22 : V1
23 : V2
24 : V3
25 : thd In
26 : thd V1
27 : thd V2
28 : thd V3
29 : ΣP-
30 : ΣQ-
31 : ΣPFC
32 : T°C 1
33 : T°C 2
34 : T°C 3
35 : T°C internal
36 : ΣP predicted
37 : ΣQ predicted
38 : ΣS predicted
3093 C15 2 Upper threshold value
3095 C17 1 Duration s
3096 C18 1 Day
3097 C19 1 Month
3098 C1A 1 Year
3099 C1B 1 Hour
3100 C1C 1 Minute
3101 C1D 1 Second
LAST 10 ALARMS EVENT LOG (FUNCTION 3)
Alarm n-1
COMMUNICATION

socomec DIRIS A40 Specifications

General

Type	Multifunction Meter
Display	LCD with backlight
Operating Temperature	-10 to +55 °C
Mounting	Panel mounting
Measurement Parameters	Voltage, Current, Power, Energy, Frequency
Communication	RS485, Modbus RTU
Storage Temperature	-25°C to +70°C
Protection Degree	IP20
Standards	IEC 61557-12
Accuracy	Class 0.5
Dimensions	96 x 96 mm
