socomec DIRIS A40 User Manual

DIRIS A40/A41 - RS485 - JBUS/MODBUS
®
GB
49
DIRIS A40/A41 - Ref.: 536 103 B GB
COMMUNICATION
LIST OF PARAMETERS TO BE DISPLAYED OR PROGRAMMED (FUNCTION 3, 6 OR 16)
512 200 1 Network type: –
0 : 1BL
1 : 2BL
2 : 3BL
3 : 3NBL
4 : 4BL
5 : 4NBL
513 201 1 CT secondary : A
1 : 1 A
5 : 5 A
514 202 1 CT primary A
515 203 1 Voltage input on PT:
0 : No
1: Yes –
516 204 2 PT primary V
518 206 1 PT secondary: V
60 : 60 V
100 : 100 V
110 : 110 V
115 : 115 V
120 : 120 V
173 : 173 V
190 : 190 V
519 207 1 Synchronisation of I AVG/MAX: s
Time in seconds, possible values
2 : 2 seconds
10 : 10 seconds
300 : 5 minutes (5x60s�
480 : 8 minutes (8x60s�
600 : 10 minutes (10x60s�
900 : 15 minutes (15x60s�
1200 : 20 minutes (20x60s�
1800 : 30 minutes (30x60s�
3600 : 60 minutes (60x60s�
520 208 1 Synchronisation of P/Q/S AVG/MAX: s
Time in seconds, possible values
10 : 10 seconds
300 : 5 minutes (5x60s�
480 : 8 minutes (8x60s�
600 : 10 minutes (10x60s�
900 : 15 minutes (15x60s�
1200 : 20 minutes (20x60s�
1800 : 30 minutes (30x60s�
3600 : 60 minutes (60x60s�
521 209 1 OUT 1 allocation of the pulse output: –
0 : kWh +
1 : kvarh +
2 : kVAh
3 : kWh -
4 : kvarh -
522 20A 1 OUT1 impulse value: –
0 : 0.1 kWh/kvarh/kVAh
1 : 1 kWh/kvarh/kVAh
2 : 10 kWh/kvarh/kVAh
Decimal Hexa. Number Text Unit
address address of words

socomec DIRIS A40 Specifications

General

Type	Multifunction Meter
Display	LCD with backlight
Operating Temperature	-10 to +55 °C
Mounting	Panel mounting
Measurement Parameters	Voltage, Current, Power, Energy, Frequency
Communication	RS485, Modbus RTU
Storage Temperature	-25°C to +70°C
Protection Degree	IP20
Standards	IEC 61557-12
Accuracy	Class 0.5
Dimensions	96 x 96 mm
